Mec Speed Level Series Service & Parts Manual page 307

Secton 16 - Base
Item Part Number Description
Additional attaching engine parts found earlier in this section
-- 91035 Engine Subassembly, Dual Fuel
1 91125 Engine, Kubota DF752
2 8472 Radiator
3 90227 Alternator, 40 AMP
4 8365 Starter
5 91175 Oil Pressure Switch
6 HDW91187 Fitting, 1/8 NPT, M-F
7 8516 Oil Filter
8 91115 Muffler
-- 92164 Gasket, Exhaust (Not Shown)
9 91776 Tail Pipe
10 92533 Clamp 1-1/2|
11 -- --
12 -- --
13 93632 Air Cleaner Assembly
14 91136 Air Filter Element
15 91188 Intake Hose
16 91340 Hose, 2.00" I.D. Flex
17 7545 Hose Clamp
18 91799 Breather Cap
19 91133 Carburetor Flange
20 91617 Carburetor Assembly
21 91130 Hub
22 91129 KTR Housing Kit, DF752
22a 91573 Coupler, Outer
23 91160 Hydraulic Pump
24 HDW6433 Screw, 3/8-16 × 1"
25 91765 Ring Gear
26 91766 Flywheel
27 21020 Bracket, Components
28 91177 Fuel Pump
29 6458 Hose, Fuel, 5/16
30 7788 Hose Clamp, 5/16
31 8514 Fuel Filter
32 50015 Screw, M8 x 50
33 50048 Nut, M8 Nylock
34 7406 Hose Assembly, LP
35 HDW6894 Elbow, 90° Brass
36 91132 Valve, Lockoff
37 91197 LP Hose, ½"
38 91198 Radiator Hose, 3/8"
39 91232 Hose Clamp, #8
40 9833 LPG Regulator
41 91119 Solenoid, Throttle
42 HDW9247 Screw, Cap Socket Head, ¼–28 × 1.0"
Page 300
Qty.
--
1
1
1
1
1
1
1
1
--
1
1
--
--
1
1
1
1
2
1
1
1
1
1
--
1
2
1
1
1
1
As Req
5
1
2
2
1
1
1
10 in
60 in
6
1
1
1
As Req - As Required
Speed Level Seres - Servce & Parts Manual
Item Part Number Description
Additional attaching engine parts found earlier in this section
43 HDW91231 Jamnut, ¼–28
44 50028 Screw, M6 x 20
45 50047 Nut, M6 Nylock
46 91375 Relay, Throttle
47 91375 Choke Bracket
48 9502 Choke Solenoid
49 9498 Choke Linkage
50 HDW91283 Screw, M6–1.0 × 25
51 20204 Spacer
52 9252 Throttle Linkage
53 92944 Solenoid Gas Shutoff
54 92945 Solenoid Propane Shutoff
55 92944 Wire Assembly, Gas Shutoff Solenoid
56 91046 Manifold Exhaust
57 91559 Gasket Muffler Flange
January 2019
Qty
2
6
6
1
1
1
1
1
1
1
1
1
1
1
1
