Groen CC20-E Operator's Manual page 81

(Revised 1/02)
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Figure 7. Water Inlet and Drain
Description
Valve Housing Assembly . . . .
Top Valve Assembly . . . . . . . .
Vent Hose . . . . . . . . . . . . . . .
Hose Clamp . . . . . . . . . . . . .
Drain Seal . . . . . . . . . . . . . . .
Drain Pipe Assembly . . . . . . .
Drain Hose . . . . . . . . . . . . . .
Hose Clamp . . . . . . . . . . . . .
Drain Elbow Assembly . . . . .
Spray Nozzle . . . . . . . . . . . . .
Valve and Bracket Assembly
• Hose Clamp . . . . . . . . . . . .
• Silicone Tube . . . . . . . . . . . .
• Drain Valve . . . . . . . . . . . . .
• Valve Mounting Tray . . . . .
• Nut, 10-32 . . . . . . . . . . . . . .
Water Inlet Assembly
Gasket . . . . . . . . . . . . . . . . . .
Condensate Tube, 28-1 /2" Lg . . 1
Water Fill Tube ,17" Lg . . . . .
Hose Clamp . . . . . . . . . . . . .
Solenoid Valve (2-Way) . . . . .
Rear Insulation Panel . . . . . .
Probe & Drain Valve Harness
Flow Restrictor . . . . . . . . . . . .
CC20-E
Parts List
Part
Qty. No.
1 081601
1 081662
1 080689
2 010873
1 080634
1 080666
1 080688
2 013616
1 080781
1 122839
1 081671
2 071271
1 080631
1 071234
1 081612
2 071256
. . . . . . 1 072151
1 072183
081626
1 081627
4 071271
1 071235
1 080696
1 076495
1 112720
3-49 3-49 3-49 3-49 3-49 3-49
