CC10-E
Parts List
2-26
Item
Description
1
Drip Tray . . . . . . . . . . . . . . . . .
2
Left Side Door Switch . . . . . .
3
Left Side Rack . . . . . . . . . . . .
4
Middle Rack . . . . . . . . . . . . . .
5
Door Assembly . . . . . . . . . . . .
6
Shroud Assembly . . . . . . . . . .
7
Baffle Assembly Cover . . . . . .
8
Right Side Door Switch . . . . .
9
Door Pin Locking Nut . . . . . . .
10
Door Latch Pin . . . . . . . . . . . .
Figure 4. Doors, Racks and Tray
Part
Qty.
No.
1
070471
1
078903
1
070180
4
069764
1
See Fig. 7
1
078920
1
070165
1
078904
1
003823
1
078914
(Revised 5/96)
