IMPORTANT INFORMATION I KEEP FOR OPERATOR I IMPORTANT INFORMATION
INSTALLATION INSTRUCTIONS
FOR GROEN CASTER KITS
Part No. 150528, Rev. A
Eclipse Braising Pans (Models BPM or BPP – G or E)
Steamers (Models VRC, SSB or HY)
Combo Ovens (Models CC-10 or C/2 – G or E)
TS-9 Stands (for table top units - Kettle Models TDB, TDH,
Braising Pan Model TD/FPC or Cooker Mixer TDB; TA/2)
OPERATORS AND INSTALLING TECHNICIANS
SHOULD READ, UNDERSTAND AND FOLLOW
WARNINGS AND INSTRUCTIONS IN THIS MANUAL
Advertisement
Related Manuals for Groen CC-10
Summary of Contents for Groen CC-10
- Page 1 Eclipse Braising Pans (Models BPM or BPP – G or E) Steamers (Models VRC, SSB or HY) Combo Ovens (Models CC-10 or C/2 – G or E) TS-9 Stands (for table top units - Kettle Models TDB, TDH, Braising Pan Model TD/FPC or Cooker Mixer TDB; TA/2)
- Page 2 Eclipse Braising Pans (Models BPM or BPP – G or E) Steamers (Models VRC, SSB or HY) Combo Ovens (Models CC-10 or C/2 – G or E) TS-9 Stands (for table top units - Kettle Models TDB, TDH, Braising Pan Model TD/FPC or Cooker Mixer TDB; TA/2)
-
Page 3: Installation Procedure
INSTALLATION INSTRUCTIONS FOR GROEN CASTER KIT (Groen Part #146354) ECLIPSE BRAISING PANS WARNING: 1. WHEN INSTALLING ON A GAS BRAISING PAN, THESE CASTERS MUST BE INSTALLED WITH A GROEN GAS QUICK DISCONNECT SUPPLY KIT (GROEN PART #140144) OR A GAS HOSE WITH MAXIMUM LENGTH THAT IS LONGER THAN THE RESTRAINING CABLE. - Page 4 GROEN CASTER KIT Figure 2 Figure 3 Figure 4 6. Install label (Groen Part #084286) as shown in Figure 2. 7. Install clasp of restraining cable to hole in braising pan frame as shown in figure 3. 8. Completed assembly should look as shown in Figure 4.
- Page 5 INSTALLATION INSTRUCTIONS FOR GROEN CASTER KIT (Groen Part #098611) SSB, VRC AND HY STANDS NOTE: DO NOT INSTALL CASTERS ON HYPLUS MODELS WARNING: 1. WHEN INSTALLING ON A GAS STEAMER, THESE CASTERS MUST BE INSTALLED WITH A GROEN GAS QUICK DISCONNECT SUPPLY KIT (GROEN PART #140144 OR A GAS HOSE WITH MAXIMUM LENGTH THAT IS LONGER THAN THE RESTRAINING CABLE.
- Page 6 GROEN CASTER KIT Figure 6 Figure 7 7. Anchor the restraining cable bracket to a secure structure. One of the preferred locations is on the concrete floor using anchor bolts (not provided) as shown in Figure 7.
- Page 7 Figure 8 Install label (Groen Part # 084286) to the steamer side panel as shown in Figures 8 or 9. NOTE - This label must be adjacent to the eye-bolt. Figure 10 10. After installation pull out the steamer to fully stretch the cable and verify that the gas hose or electrical conduit are not under tension or stretched.
- Page 8 2. Remove the factory installed bullet feet. 3. Insert casters into place. 4. Level the combo oven front to back and left to right by adjusting the casters accordingly. Figure 11 5. Drill a 13/32” (0.406” or 9 mm) diameter hole through one of the rear legs of table approximately 3”...
- Page 9 Install clasp of restraining cable to hole in restraining cable bracket and eye-bolt. 10. After installation pull out the combination oven to fully stretch the cable and verify that the gas hose or electrical conduit are not under tension or stretched.
- Page 10 GROEN CASTER KIT INSTALLATION INSTRUCTIONS FOR GROEN CASTER KIT ON TS-9 STAND FOR TABLE TOP KETTLES WARNING: 1. WHEN INSTALLING ON A TABLE WITH GAS KETTLE, THESE CASTERS MUST BE INSTALLED WITH A GROEN GAS QUICK DISCONNECT SUPPLY KIT (GROEN PART #140144) OR A GAS HOSE WITH MAXIMUM LENGTH THAT IS LONGER THAN THE RESTRAINING CABLE.
- Page 11 Figure 17 4. Install label (Groen Part # 084286) to the back of kettle control box as shown above in Figure 17. Figure 18 5. Install clasp of restraining cable to hole in restraining cable bracket and eye-bolt (Figures 16 and 18). 6.
- Page 12 1055 Mendell Davis Drive Jackson, MS 39272 Telephone 601 372-3903 Fax 601 373-9587 www.groen.com INSTALLATION INSTRUCTIONS FOR GROEN CASTER KITS Part No. 150528, Rev. A...
