Table Of Contents - Groen CC20-E Operator's Manual

(Revised 1/02)
Item
1 Fuse, 0.2 Amp., Slow Blow . . . . . . .
Prior to Serial No. C7439MS
3 Relay Board Retrofit Kit . . . . . . . . . .
Cook Only . . . . . . . . . . . . . . . . . . . .
Cook annd Hold . . . . . . . . . . . . . . . .
Starting at Serial No. C7439MS
3 Relay Board . . . . . . . . . . . . . . . . . .
5 Fuse, 2 Amp . . . . . . . . . . . . . . . . . . .
6 Fuse, 20 Amp . . . . . . . . . . . . . . . . . .
7 Transformer . . . . . . . . . . . . . . . . . . .
8 Bridge Rectifier . . . . . . . . . . . . . . . .
9* Control Panel . . . . . . . . . . . . . . . . . .
Prior To Serial No. C7439MS
Single Oven
Cook Only Retrofit Kit . . . . . . . . . . .
Cook and Hold Retrofit Kit . . . . . . . .
Double Stacked
Top, Cook Only Retrofit Kit . . . . . . .
Bottom, Cook Only Retrofit Kit . . . . .
Top, Cook and Hold Retrofit Kit . . . .
Bottom, Cook and Hold Retrofit Kit . . .
Starting At Serial No. C7439MS
Single Oven
+ Cook Only . . . . . . . . . . . . . . . . . . . .
+ Cook and Hold . . . . . . . . . . . . . . . . .
Double Stacked
*+ Top, Cook Only . . . . . . . . . . . . . . . .
*+ Bottom, Cook Only . . . . . . . . . . . . . .
*+ Top, Cook and Hold . . . . . . . . . . . . .
*+ Bottom, Cook and Hold . . . . . . . . . .
+ EPROM . . . . . . . . . . . . . . . . . . . . . .
10 Surge Suppressor, 208/240V . . . . . .
11 Terminal Block . . . . . . . . . . . . . . . . .
12 Harness Line Side . . . . . . . . . . . . . .
13 Harness Heater Side . . . . . . . . . . . .
14 Harness Drain and Air Probe . . . . . .
15 Control Panel Knob . . . . . . . . . . . . .
16 Voltage Plug . . . . . . . . . . . . . . . . . . .
17 Flexible Cable with Grounded Shield
* Change the mounting frame with the old panel.
+ EPROM must be ordered with control panel.
Figure 4. Control Panel and Relay
Bracket Assembly
Description
CC10-E
Parts List
Part
Qty. No.
2 073271
1 070184
1 112980
1 112988
1 120718
1 071488
3 071489
1 071490
1 071487
1 112980
1 112982
1 112980
1 112980
1 112982
1 112982
1 112960
1 112961
1 112960
1 112960
1 112961
1 112961
1 112954
1 098703
1 070185
1 072101
1 072187
1 073272
1 073430
1 106826
1 114423
2-27
