Drain Valve
Removal
Be sure oven is disconnected from branch circuit power
before performing any repair work.
1. Turn off oven power and disconnect oven from the branch circuit.
2. For the CC10-E, CC20-E, and CC20-G units, remove back cover. For the
CC10-G remove the right side cover.
3. Loosen hose clamps and disconnect both ends of drain hose.
4. Disconnect valve electrical wires from valve harness.
5. Remove valve and bracket as an assembly from the oven. Remove valve from
bracket.
Installation
1. If silicone hose is damaged, replace it.
2. Attach drain valve to valve bracket.
3. Pull silicone hose through drain valve and loosely install hose clamps over
both ends of hose.
4. Position bracket over bracket mounting holes and connect both ends of hose.
Tighten hose clamps. Be careful not to overtighten clamps.
5. Install and tighten valve bracket mounting screws. Be sure drain tube is
properly aligned and doesn't have any kinks, bends, and/ or twists.
6. Connect valve electrical leads to valve harness.
7. Connect oven to the branch circuit and turn on oven power.
8. Operate oven in Steam mode. Allow boiler to fill. Check for leaks and observe
if drain valve fully closes.
9. Operate oven in Oven mode and check if boiler is draining. Also check for
leaks.
10. Install back cover
