Groen CC20-E Operator's Manual page 133

Item Description
Door Assembly ........................
1 Handle .....................................
2 Truss Head Screw S.S............
3 Door Front Panel.....................
4 Insulator Board .......................
5 Hinge ......................................
6 Door Spacer ............................
7 Gasket ....................................
8 Inner Panel .............................
9 Hex Head Cap Screw S.S. .....
10 Latch Assembly .......................
11 • Retaining Ring ......................
12 • Spring Support Pin ..............
13 • Door Spring...........................
14 Block and Magnet Assembly...
15 Door Cam ...............................
(Revised 1/02)
Part
Qty. No.
1 073284
1 129723
6 005764
1 073281
1 070110
1 070199
4 071206
1 070121
1 070112
2 005608
1 078906
2 073278
Item
1 073280
*
1 078911
*
1 069762
1 074252
* Not Shown
Figure 7. Oven Door
Description
Loctite 242...............................
RTV Sealant 159.....................
CC10-G
Parts List
Part
Qty. No.
1 073282
1 078939
