(Revised 1/02)
Installation - Gas Units
Be sure oven is disconnected from branch circuit power
before performing any repair work.
1. If male fitting was removed with the probe assembly, install it in the oven at this
time and securely tighten it.
2. Install new compression nut and boiler temperature probe. Be careful not to
bend the probe as you insert it through the male fitting and through the eye of
the probe mounting bracket. Securely tighten probe compression nut.
3. Route probe wires away from any high voltage wires and sharp edges.
Connect probe wires to the harness.
4. Install right side cover.
5. Connect oven to the branch circuit.
6. Turn on oven power and perform the following reset procedure;
a) Turn off oven power by pressing the ON touch pad.
b) While pressing the COMBO touch pad, press the ON touch pad.
If no errors are found, the unit will beep and show four zeros in the Time
display window. If errors are found, the unit will not beep and service code
will be displayed in the Time window. If there are more than four different
errors at one time, some of the numbers will be displayed in the
Cook Temperature window.
c) Press the CLEAR touch pad. Select Combo mode.
d) If the Service light comes on and service codes are displayed, record the
service code number or numbers. Press the CLEAR touch pad and repeat
steps a and b.
e) If the Service light does not come on, the oven should be ready for
operation.
Maintenance
Replacement Procedures
WARNING
8-17
