Bracket Assy 1 - Groen CC20-E Operator's Manual

CC20-E
Parts List
3-44 3-44 3-44 3-44 3-44 3-44
Item
1 Bracket Assy . . . . . . . . . . . . . .
070100
2 Motor & Heat Stinger Assy.
081666
2 Motor & Heat Stinger Assy.
081667
3 Key, 1/8" Square 303 S.S. . . .
4 Insulation Retainer Assy. . . . .
5 Insulation Nut Plate .. . . . . . . .
6 Motor Seal Assy . . . . . . . . . . .
071299
• Washer Seal Housing . . . . .
• Packing . . . . . . . . . . . . . . . .
• Motor Shaft Housing Seal . .
7 Washer, Fiber . . . . . . . . . . . .
8 Screw, Truss Head S.S. . . . . .
9 Wheel Blower Assembly . . . .
10 Washer, Flat . . . . . . . . . . . . . .
Figure 2. Fan and Motor
MOTOR
13
Description
- 208/240V . . . . . . . . . . . . . .
- 480V . . . . . . . . . . . . . . . . . .
Part
Qty. No.
1
1
1
1 071288
1 071228
1 069770
1
1 070458
3 070459
1 070457
3 071300
3 081698
1 080681
1 059228
(Revised 1/02)
