CC20-G
Parts List
5-30
Item
Description
-
Door Assembly ........................
2
Control Panel Knob .................
3
Shroud with Right Side Rack ..
4
Right Side Door Switch ...........
5
Middle Rack ............................
6
Drip Tray..................................
7
Left Side Door Switch .............
8
Left Chamber Baffle ................
9
Door Pin Locking Nut ..............
10
Door Latch Pin ........................
11
Top Interior Panel ....................
12
Bottom Interior Panel ..............
Figure 6. Door, Racks, and Tray
Part
Qty.
No.
1
See
Fig. 7
1
073430
1
090789
1
081620
5
080644
1
080772
1
081621
1
090771
1
003823
1
078914
1
086349
1
086350
(Revised 1/02)
