Maintenance
Replacement Procedures
Door Switches
Installation
CC10-E
1. Connect ohmmeter leads to door switch terminals, and hold switch
approximately one inch from oven door magnet. Switch should close at this
distance as indicated by a short circuit reading on the meter.
2. Route door switch wires away from sharp edges and high voltage wires, and
connect wires to the relay board. Store excess wire under relay board bracket.
3. Slide front panel into its normal installed position.
4. Attach side cover mounting bracket to the front panel.
5. Tighten one of the KEPS nuts at top left corner of oven, but be careful not to
overtighten.
6. Install door bullet and jam nut (see page 8-36), and the two screws above and
below the bullet.
7. Install drip tray.
8. Install control panel. See page 8-24.
9. Install L-cover and right side cover.
10. Operate oven in Oven mode. Open and close the door. Oven should operate
only when the door is closed.
CC20-E, CC10-G, and CC20-G
1. Connect ohmmeter leads to door switch terminals, and hold switch
approximately one inch from oven door magnet. Switch should close at this
distance as indicated by a short circuit reading on the meter.
2. Install a good door switch on the switch bracket.
3. Route door switch wires away from sharp edges and high voltage wires, and
connect wires to the relay board. Store excess wire under the insulation.
4. Install switch assembly. Push on bracket until assembly locks into place in
front panel.
5. Install control panel (see page 8-24).
6. Operate oven in Oven mode. Open and close the oven door. Fan should
operate only when the door is closed.
7. Install right side cover.
