Groen CC20-E Operator's Manual page 293

(Revised 1/02)
Boiler Heating Element (Electric Units Only)
Be sure oven is disconnected from branch circuit power
before performing any repair work.
Removal
1. Turn off oven power and disconnect oven from the branch circuit.
2. Remove right side cover.
CC10-E
3. Disconnect electrical wires from heater element being replaced. Remove
boiler baffle plate.
CC20-E
3. Disconnect wires, for heater element being replaced, from the terminal block.
4. Remove the center and right side racks, and boiler cover.
CC10-E
5. Remove two mounting nuts, flat washers, and fiber washers from heater
element. Use a 3/4 inch deep socket, 1/2 inch drive.
CC20-E
5. Remove two mounting nuts, flat washers, and fiber washers from heater
element. Use a 1-1/16 inch deep socket, 1/2 inch drive.
6. Remove boiler heating element.
Installation
1. Carefully install boiler heating element; then install a new fiber washer,
flat washer, and nut at each end of the element.
2. Install boiler baffle plate.
3. Check that the element is not touching the bottom of the boiler; then tighten
the two mounting nuts. Again check that the element is not touching the
bottom of the boiler.
CC10-E
4. Connect heater element wires to the element.
Maintenance
Replacement Procedures
WARNING
8-49
