Groen CC20-E Operator's Manual page 100

C/2-E
Parts List
3A-18 3A-18
Item Description
1 Assembly, Door Front Panel ...
2 Screw, #10-32 x .375 Phillips
Flat Head .............................
3 Handle .....................................
4 Spacer, Cam ...........................
5 Assembly, Cam .......................
6 Screw, #8-32 x 1.00 Phillips
Torx Head Locking ...............
7 Screw, #8-32 x .375 Phillips
Torx Head Locking ...............
8 Assembly, Door Magnet ..........
9 Nut, #10-32 SS .......................
10 Mandrel, Spring.......................
11 Spring ......................................
12 Spacer, Door Latch .................
13 Weldment, Door Latch
Bracket.................................
14 Weldment, Door Inside
Panel....................................
15 Spring, Extension ....................
16 Weldment, Retention Clip
Mounting Bracket .................
17 Clip, Inner Door Retention ......
18 Assembly, Inner Door..............
19 Gasket, Inner Door..................
20 Bumper, Stem .........................
21 Bracket, Condensate
Deflector...............................
22 Screw, #8-32 x .375 Phillips
Flat Undercut Head..............
23 Screw, 1/4-20 x .50 Phillips
Flat Head .............................
24 Hinge, with Mounting Hole ......
25 Assembly, Light Box Cover .....
26 Lamp .......................................
27 Assembly, Light Bar Insulator .
28 Screw, #8/32 x .50 Socket
Button Head .........................
29 Nut, #8-32 with SEMS.............
30 Clip, Fuse 13/32 Dia. S.S. ......
31 Washer, #10 Shoulder.............
32 Washer, #10 ............................
33 Nut, #10-32 with SEMS...........
34 Weldment, Light Box
Bracket.................................
35 Cord, Jumper-Door Light ........
Part
Qty. No.
1 133847
8 069723
1 129723
2 123744
1 074252
2 123718
6 129732
1 129726
1 002632
1 130864
1 078911
1 094146
1 123572
1 123528
2 123592
2 123540
2 123539
1 123548
1 123596
6 123588
1 138389
6 127178
2 123721
2 123507
1 123570
4 112733
1 123597
2 093255
2 069784
2 112735
1 123866
1 014812
1 071256
1 123569
1 127174
(Revised 1/02)
