Prior To Serial No. C7439Ms - Groen CC20-E Operator's Manual

(Revised 1/02)
Item
14
15
10
11*
12
13
14
15
* When replacing these parts be sure to install a surge
suppressor if not already installed.
** EPROM must be ordered with control panel.
Figure 5. Control Panel, and Relay Board
and Transformer Assembly
Description
1 Fuse, 0.2 Amp., Slow Blow . .

Prior to Serial No. C7439MS

3 Relay Board Retro Kit
Cook . . . . . . . . . . . . . . . . . . . .
Cook and Hold . . . . . . . . . . . .
Starting at Serial No. C7439MS
3 Relay Board . . . . . . . . . . . . .
5 • Fuse, 3 Amp . . . . . . . . . . . .
6 • Fuse, 4 Amp . . . . . . . . . . . .
7 • Fuse, 20 Amp . . . . . . . . . . .
8 • Transformer, 100VA . . . . . .
9 • Transformer, 50V
(480V Units Only)
• Bridge Rectifier . . . . . . . . . .
Control Panel
Prior to Serial No. C7439MS
Single Oven
Cook Only . . . . . . . . . . . . . . .
Cook and Hold . . . . . . . . . . .
Double-Stacked
Top, Cook Only . . . . . . . . . . .
Bottom, Cook Only . . . . . . . .
Top, Cook and Hold
Bottom, Cook and Hold . . . . .
Starting at Serial No. C7439MS
Single Oven
** Cook Only . . . . . . . . . . . . . . .
** Cook and Hold . . . . . . . . . . .
** EPROM . . . . . . . . . . . . . . . . .
Double-Stacked
** Top, Cook Only . . . . . . . . . . .
** Bottom, Cook Only . . . . . . . .
** Top, Cook and Hold
** Bottom, Cook and Hold . . . . .
Control Panel Knob . . . . . . . .
Fuse Block . . . . . . . . . . . . . . .
Voltage Plug . . . . . . . . . . . . . .
Flex Cable . . . . . . . . . . . . . . .
CC20-E
Parts List
Part
Qty. No.
2 073271
1 112980
1 112983
1 120719
1 077853
1 077837
3 071489
1 077838
. . . . . . . 1 099294
1 071487
1 112960
1 112961
1 112960
1 112960
. . . . . . . 1 112961
1 112961
1 112960
1 112961
1 112955
1 112960
1 112960
. . . . . . . 1 112961
1 112961
1 073430
1 077840
1 106826
1 114423
