CC10-E
Operation
After Serial Number C7439MS
The model CC10-E is a combination steamer-oven with a stainless steel cooking
chamber, a steam generator, and electronic circuitry for controlling unit operation.
It can operate from a single-phase or three-phase, 208 or 240 volt, 60 hertz power
source.
It can function as a convection oven, a self-contained pressureless steamer, or as
a combination oven-steamer. Mode of operation is controlled by the control panel
touch pad switches. Hold mode is optional.
Replaceable electric (air) elements and the blower fan provide oven temperatures
up to a maximum of 575°F.
Replaceable heating elements are used to generate steam. The steam generator
cavities are adjacent to the cooking compartment and easily accessible. All of the
condensate leaves the oven through the cavity drain. When the unit is turned off
the steam generator automatically drains. When the oven cooking mode is
selected, the steam generator cavity automatically drains. When no mode is
selected the steam generator fills and water is held at 160°F.
The control panel is a solid-state controller. The solid-state circuitry has a self-
diagnostic program to assist you in troubleshooting, and a pre-programmed
cleaning cycle to assist the operator in daily cleaning.
The door interlock switch operates to turn off the fan and oven/ steamer elements
when the door is opened.
The electrical circuits that are active for the three operating modes are shown in
the following illustrations.
