Item
1
Auto Clean Tank .....................
2
Screw, 318" Truss Hd .............
3
Swing Check Valve.................
4
Filler Cap ................................
5
Elbow 90°, 3/8-18N PT...........
6
Close Nipple, 3/8-18NPT........
7
Male Adapter, 1/2-14NPT X
112 Hose ................................
8
Eductor,1/2-14NPT .................
9
Male Adapter, 90° ...................
10
Swing Check Valve,
1/2-14NPT ..............................
(Revised 1/02)
Description
Figure 11. Auto Clean Single Stack Piping Assembly
Part
Qty.
No.
Item
1
086452
11
1
005764
1
086461
12
1
086468
13
1
086490
14
1
086493
15
1
092104
16
1
086460
17
1
086489
18
19
1
086461
Description
Nipple, 1/2-14NPT X 1-1/2
Lg ............................................
Elbow 900,1 /2-14N PT...........
Plug, 3/8-18NPT .....................
Screw, Hex Head,
8-32 X 3/8 ...............................
Bracket ...................................
O-Ring, 1-3/8 X 2 X 3/16" .......
Hose to Boiler .........................
Hose from Water Valve ...........
Hose Clamp ............................
CC20-G
Parts List
Part
Qty.
No.
3
086485
2
086494
1
092103
2
069789
1
086457
3
092102
1
092116
1
092115
4
092121
5-35
