Groen CC20-E Operator's Manual page 164

CC20-G
Parts List
5-26
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
* Not Shown
Figure 2. Fan and Motor
MOTOR
13
Description
Bracket Assy ...........................
Motor & Heat Stinger Assy......
Key, 1/8" Square 303 S.S. ......
Insulation Retainer Assy .........
Insulation Nut Plate .................
Motor Seal Assy ......................
• Washer Seal Housing ...........
• Packing .................................
• Motor Shaft Housing Seal.....
Washer, Fiber ..........................
Screw, Truss Head S.S. ..........
Wheel Blower ..........................
Washer, Flat ............................
Washer, Lock...........................
Screw, Hex Head Cap S.S......
Kit Fan Isolator ........................
Part
Qty. No.
1 070100
1 090760
1 071288
1 071228
1 069770
1 071299
1 070458
3 070459
1 070457
3 071300
3 081698
1 086380
1 059228
1 05656
1 05613
1 104295
(Revised 1/02)
