Water Inlet Valve
Be sure oven is disconnected from branch circuit power
before performing any repair work.
Removal
The water inlet valve for the CC10-E, CC20-E, and older CC10-G units has
two solenoids, one for the boiler fill and one for the condensate spray. The
CC10-G and CC20-G, with auto clean, have a water inlet valve with three
solenoids, one each for the boiler fill, condensate spray, and cleaning cycle.
1. Turn off oven power and disconnect oven from the branch circuit.
2. CC10-E, CC20-E, and CC10-G: Remove right hand side cover and back
cover.
CC20-G: Remove the back cover.
3. Shut off oven water supply.
4. Remove valve from the oven.
5. Disconnect hoses from valve.
6. Check if electrical leads to the solenoids are legible. If necessary, identify and
label the wires.
7. Disconnect electrical leads from the solenoids.
Installation
1. Correctly connect electrical leads to the solenoids.
2. Install valve and tighten mounting screws.
3. Connect the hoses, and tighten hose clamps and inlet water hose connector.
Do not overtighten.
4. Turn on oven water supply and check for leaks. If necessary, add a hose
washer at the water inlet port.
When oven power is turned on, there is high voltage present
in the electrical components compartment.
5. Connect oven to the branch circuit and turn on oven power.
Maintenance
Replacement Procedures
WARNING
IMPORTANT
WARNING
8-27
