To change the test lead compensated value:
1. Push the Series R softkey.
Use the cursor keys, rotary knob, or numerical keyboard to setup new test
2.
lead resistance and push the Ohm softkey or push ENTER or push in the
rotary knob.

Set the High Resistance Source Output

The Product sources high resistance through its OUTPUT terminals. The
standard high-resistance output is up to 100 GΩ (fixed value) with a maximum
applied voltage of 1575 V dc. The 5322A/5 is fitted with a high-resistance source
with variable resistance up to 100 GΩ with a maximum applied voltage of 5.5 kV
dc. The maximum acceptable voltage on any resistance output is dependent on
the selected range and is also listed in Table 10.
Table 10. High Resistance Ranges with Maximum Voltage Rating
Resistance Range
10.000 kΩ to 39.99 kΩ
40.00 kΩ to 99.99 kΩ
100.00 kΩ to 199.99 kΩ
200.0 kΩto 999.9 kΩ
1.000 MΩ to 1.999 kΩ
2.000 MΩ to 9.999 MΩ
10.000 MΩ to 100 GΩ
[1] Maximum test voltage with the supplied stackable 4 mm banana leads is 1000 V. For higher
voltages, use the XHL-5000 high voltage test lead.
Use the high voltage resistance multiplier to increase the resistance range to
10 TΩ with a maximum test voltage of 10 kV dc.
Maximum Applicable Voltage DC
5322A
Standard 1.5 kV Version
65 V
400 V
[1]
800 V
[1]
1100 V
1575 V
[1]
[1]
1575 V
1575 V
[1]
Multifunction Electrical Tester Calibrator
Set the High Resistance Source Output
5322A/5
5 kV Version
65 V
400 V
[1]
800 V
[1]
1100 V
1575 V
[1]
[1]
2500 V
5500 V
[1]
