[SOUR]:SAF:LRES:LOW(?) <CPD> {FLOat | GROund}
Description: This command connects or disconnects the Low Resistance Lo
terminal to/from GND terminal. If not already selected, this
command switches the Product to the Low-Resistance mode
(function Resistance).
Parameters: <CPD>
Example: SAF:LRES:LOW GRO
Query: SAF:LRES:LOW?
[SOUR]:SAF:LRES:SRES(?) <CPD>
Description: This sets the series resistance value. If not already selected, this
command switches the Product to the Low-Resistance mode
(function Resistance).
Parameters: (DNPD>
Example: SAF:LRES:SRES 0.085
Query: SAF:LRES:SRES?
[SOUR]:SAF:LRES:ARES(?) <CPD> { SHORt | 0K5 | 1K0 | 2K0 | 5K0 }
Description: This sets the auxiliary resistance value. If not already selected, this
command switches the Product to the Low-Resistance mode
(function Resistance).
Example: SAF:LRES:ARES 0K5
Query: SAF:LRES:ARES?
•
SHORt – short circuit between voltage and current terminals
• 0K5 – 500 Ω between voltage and current terminals
•
1K0 – 1 kΩ between voltage and current terminals
•
2K0 – 2 kΩ between voltage and current terminals
•
5K0 – 5 kΩ between voltage and current terminals
Multifunction Electrical Tester Calibrator
GROund grounds the Low-Resistance output
FLOat floats the Low-Resistance output from
ground
Grounds the Lo resistance output
terminal Lo.
The Product returns GRO when the
output is grounded or FLO when floating
Parameter represents the value of
the series resistance expressed in
Ohms. See the Specifications (found
online at www.Flukecal.com) for
acceptable ranges.
Series resistance 0.085Ω
The Product returns the set value of
resistance using exponential format.
Example: 0.1 Ω is returned as
0.100e+00
Sets auxiliary resistance to 500 Ω.
The Product returns selected value of
auxiliary resistance.
