Technical Specifications - Danfoss HFX Series Installation And Operation Manual

HFX Product Family
2.0

TECHNICAL SPECIFICATIONS

Danfoss HFX Controllers
Dimensions
Weight
Storage Temperature Range
Operating Temperature Range
IP Rating
Operating Altitude
Supply Voltage
Reverse Polarity Protection
Peak Supply Voltage
Maximum Current
Idle Current 12/24 VDC
Standby Current 12/24 VDC
Ignition Pin (K15)
CPU Type
Frequency
Bit Width
FPU
Data Memory (RAM retain) (additional to cpu)
Flash (ROM program & data combined)
SRAM
EEPROM
CAN Speci cation
Baud Rates
Protocol
Default Node Address
Default Baud Rate
USB Speci cation
Baud Rates
Default Node Address
Default Baud Rate
Number of Sensor Supplies
Sensor Supply Output Voltage
Sensor Supply Maximum Current
Analog Input Resolution
Accuracy
Measuring Ranges
Short Circuit Protection
Open Circuit Detection
Input Sampling Frequency
Input Type
Maximum Input Frequency
Switch -on Level
Switch -o Level
Input Type
Maximum Input Frequency Ch 3 -8 (FREQ) (0 -5 V square wave)
Maximum Input Frequency Ch 3 -8 (Dig)
Switch -on Level
Switch -o Level
6 HFX Product Family Installation and Operation Manual for C-API April 2017
212.61mm L x 134.17mm W x 58.55mm H
43.2 ounces (1225 grams)
-40 - +125 °C
-40 - +105°C (USB use is limited to 85°C)
IP67/IP69K
0-4000 m
6-32 VDC, Nominal operation @ 12 /24 VDC
Integrated
36 VDC
48 A @ 85°C (40 A @ 105°C)
TBD
<3.5mA@12V, <2.5mA@24V
Enable/Disable standby mode
Renesas Super H 72546
200 MHz
32 Bit
Integrated on chip
32 Kbyte (4 Kbyte available to user.)
3.75 Mbyte
256 Kbyte
128 Kbyte
2.0A, 2.0B
50 kb/s,100 kb/s,125 kb/s,250 kb/s,500 kb/s,800 kb/s,1Mb/s
Partial SAEJ1939 support
0
250kb/s
N.A.
N.A.
N.A.
N.A.
1 for HFX 12/20; 2 for HFX32/48
5 VDC or 10 VDC (con gurable)
200 mA @ 5VDC, 100 mA @ 10V per supply
12 bits, *10 bits
+/- 1 % FS
0...5 V, 0...10 V*, 0...32 V , 0...20 mA (Ratiometric)
Integrated
Dependent upon selectable termination
1 kHz
Digital Low/High Side (Software con gurable)
200 Hz
Software con gurable
Software con gu rable
Frequency, Digital Low/High side, (Software con gurable)
Ch 3-8 0 Hz...50 kHz* in Freq. mode Note: maximum aggregate is 200 kHz,
Minimum detectable pulse duration is 20 µsec
Standard switch on at 3.0 V
Standard switch o at 2.0 V
