Technical Specifications

6.1

Technical data

Nominal voltage
Power consumption, max .
Relay load:
Resistive (inductive, cos(phi sign) = 0,6)
Total current load limit
C1-NO1, C2-NO2
C3-NO3-NC3, C4-NO4-NC4
C8-NO8-NC8
Sensor inputs
Compatible sensors
Digital inputs
Connection specification
Cable specification for connectors terminals
Battery back-up time, min .
Ball pressure test
Pollution degree
Controller type
Operating temperatures and conditions
Storage temperature and conditions
IP class
Protection class
Immunity against voltage surges
Dimensions (H/W/D), DIN dimension :
Mounting method
Weight, net
Menu languages:
Base controller
Software class
18
DEVIreg™ Hotwater
Type
10 (3,5) A (100 000 cycles), cos(phi) = 0 .5
6 (4) A (100 000 cycles), cos(phi) = 0 .6
6 (4) A (100 000 cycles), cos(phi) = 0 .6
NTC15k (15 kOhm @ 25 °C) (standard) (max 90 °C)
NTC16k (16,7 kOhm @ 100 °C)
DI1-DI8, voltage free contacts, on/off inputs
Grouped screws plug-in connectors
CE: -20T60 / UL: 0T55, 90% RH non-condensing
-30Т85, 90% RH non-condensing
110(122) х 138 х 70 mm, 8 DIN modules
DIN rail, complying with EN 60715
Danfoss MCX08M2, item no . 080G0307
Value
110/230 V~ AC, 50–60 Hz
Analog inputs AI1-AI8
NTC10k (10 kOhm @ 25 °C)
NTC5k (5 kOhm @ 25 °C)
NTC2k (2 kOhm @ 25 °C)
NTC100 (100 kOhm @ 25 °C)
PT1000 (1000 Ohm @ 0 °C)
0,2-2,5 mm²
48 hours
2 (domestic use)
IP40 only on the front cover
Class II -
Over Voltage Category II
FEC | Produced by Danfoss ©
20 V A
32 A
125 °C
1 C
511 g
EN
A
