Specifications

9 Specifications

9.1 Electrical Data

®
VLT AutomationDrive FC 302
High/normal overload
(High overload=150% current during 60 s,
normal overload=110% current during 60 s)
Typical shaft output at 400 V [kW]
Typical shaft output at 460 V [hp]
Typical shaft output at 500 V [kW]
Enclosure size
Output current (3-phase)
Continuous (at 400 V) [A]
Intermittent (60 s overload)
(at 400 V) [A]
Continuous (at 460/500 V) [A]
Intermittent (60 s overload)
(at 460/500 V) [A]
Continuous kVA (at 400 V) [kVA]
Continuous kVA (at 460 V) [kVA]
Continuous kVA (at 500 V) [kVA]
Maximum input current
Continuous (at 400 V) [A]
Continuous (at 460/500 V) [A]
Maximum number and size of cables
per phase (E1h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
2 1)
- Brake or regen [mm (AWG)]
Maximum number and size of cables
per phase (E3h)
2
- Mains and motor [mm (AWG)]
- Brake [mm 2 (AWG)] 1)
2
- Load share or regen [mm (AWG)]
Maximum external mains fuses [A]
Estimated power loss at 400 V [W]
Estimated power loss at 460 V [W]
4)
Efficiency
Output frequency [Hz]
Heat sink overtemperature trip [°C (°F)]
Control card overtemperature trip [°C (°F)]
Power card overtemperature trip [°C (°F)]
Fan power card overtemperature trip [°C (°F)]
Active in-rush card overtemperature trip
[°C (°F)]
Table 9.1 Electrical Data for Enclosures E1h/E3h, Mains Supply 3x380–500 V AC
MG38A202
Operating Guide
N315
HO
315
450
355
E1h/E3h
600
900
540
810
416
430
468
578
520
2 (AWG)] 1) 5x240 (5x500 mcm)
2 1) 4x240 (4x500 mcm)
(AWG)]
2x185 (2x350 mcm)
1) 6x240 (6x500 mcm)
2x185 (2x350 mcm)
1) 4x185 (4x350 mcm)
2) 800
3), 4) 6178
3), 4) 5322
0.98
0–590
110 (230)
80 (176)
85 (185)
85 (185)
85 (185)
