Technical Specifications

6.1

Technical data

Nominal voltage
Power consumption, max .
Relay resistive (inductive, cos(phi) = 0,6) load:
Total current load limit
C1-NO1, C2-NO2
C5-NO5, C6-NO6
C3-NO3-NC3, C4-NO4-NC4
C7-NO7-NC7, C8-NO8-NC8
Sensor inputs
Sensing unit
Sensor failure monitoring
Digital inputs
Connection specification
Cable specification for connectors terminals
Battery back-up time, min .
Ball pressure test
Pollution degree
Controller type
Operating temperatures and conditions
Storage temperature and conditions
IP class
Protection class
Immunity against voltage surges
Dimensions (H/W/D), DIN dimension :
Mounting method
Weight, net
Menu languages:
Base controller
Software class
34
DEVIreg™ Multi
Type Value
Temperature sensors separately selectable via
software at analog inputs AI1-AI7 between:
NTC15k (15 kOhm @ 25 °C)
NTC10k (10 kOhm @ 25 °C)
NTC100 (100 kOhm @ 25 °C)
NTC16k (16,7 kOhm @ 100 °C)
Disconnected or short-circuited sensor
DI1-DI8, voltage free contacts, on/off inputs
Grouped screws plug-in connectors, pitch 5 mm
125 °C according to IEC 60730-1
CE: -20T60 / UL: 0T55, 90% RH non-condensing
-30Т85, 90% RH non-condensing
IP40 only on the front cover
Designed for Over Voltage Category II
110(122) х 138 х 70 mm, 8 DIN modules
DIN-rail, complying with EN 60715
Danfoss MCX08M2, item no . 080G0307
FEC | Produced by Danfoss ©
110/230 V AC, 50–60 Hz
20 V A
10 (3,5) A (100 000 cycles)
6 (4) A (100 000 cycles)
6 (4) A (100 000 cycles)
6 (4) A (100 000 cycles)
Analog inputs AI1-AI8
NTC5k (5 kOhm @ 25 °C)
NTC2k (2 kOhm @ 25 °C)
PT1000 (1000 Ohm @ 0 °C)
Ni100 (100 Ohm @ 0 °C)
0,2-2,5 mm²
48 hours
2 (domestic use)
Class II -
511 g
v01 .7: EN, PL, RU, UA
32 A
1 C
