Introduction

1 Introduction

1.1 How to Read This Programming Guide

1.1.1 Purpose of the Manual
This programming guide provides information about
controlling the frequency converter, parameter access,
programming, and troubleshooting.
The programming guide is intended for use by qualified
personnel who are familiar with the FC 360 frequency
converter.
Read the instructions before programming and follow the
procedures in this manual.
®
VLT is a registered trademark.
1.1.2 Additional Resources
Additional resources include:
•
®
VLT AutomationDrive FC 360 Quick Guide provide
the neccessary information for getting the drive
up and running.
•
®
VLT AutomationDrive FC 360 Design Guide
provides detailed technical information about the
drive and customer design and applications.
•
®
VLT AutomationDrive FC 360 Service Manual
provides information to Danfoss-authorised,
qualified technicians on how to service the FC
360 frequency converters.
Contact the local Danfoss supplier or go to
www.danfoss.com/fc360 to download the documentations.
1.1.3 Document and Software Version
This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition Remarks
MG06C6 Replaces MG06C5
Table 1.1 Document and Software Version
MG06C602
Programming Guide
Software version
1.5X
Danfoss A/S © 7/2015 All rights reserved.
1.1.4 Abbreviations
AC Alternating current
AEO Automatic energy optimisation
ACP Application control processor
AWG American wire gauge
AMA Automatic motor adaptation
°C
Degrees Celsius
DC Direct current
Electrically erasable programmable
EEPROM
read-only memory
EMC Electromagnetic compatibility
EMI Electromagnetic interference
ETR Electronic thermal relay
f Nominal motor frequency
M,N
FC Frequency converter
IP Ingress protection
I Current limit
LIM
I Rated inverter output current
INV
I Nominal motor current
M,N
I Maximum output current
VLT,MAX
Rated output current supplied by the
I
VLT,N
frequency converter
L Motor d-axis inductance
d
L Motor q-axis inductance
q
LCP Local control panel
MCP Motor control processor
N.A. Not applicable
P Nominal motor power
M,N
PCB Printed circuit board
PE Protective earth
PELV Protective extra low voltage
PWM Pulse width modulated
R Stator resistance
s
Regen Regenerative terminals
RPM Revolutions per minute
RFI Radio frequency interference
SCR Silicon controlled rectifier
SMPS Switch mode power supply
T Torque limit
LIM
U Nominal motor voltage
M,N
X Motor main reactance
h
Table 1.2 Abbreviations
