Examples
# Display the protocols and protocol indexes configured on all protocol-based-VLANs.
<Sysname> display protocol-vlan vlan all
VLAN ID:2
Protocol Index
======================================================
0
3
VLAN ID:3
Protocol Index
======================================================
0
1
Table 36 Command output
Field
VLAN ID
Protocol Index
Protocol Type

port hybrid protocol-vlan

Syntax
port hybrid protocol-vlan vlan vlan-id { protocol-index [ to protocol-end ] | all }
undo port hybrid protocol-vlan { vlan vlan-id { protocol-index [ to protocol-end ] | all } | all }
View
Layer 2 Ethernet interface view, port group view, Layer 2 aggregate interface view
Default level
2: System level
Parameters
vlan vlan-id: Specifies a VLAN ID, in the range of 1 to 4094.
protocol-index: Specifies a protocol index. The value can be specified by the users or assigned by
the system automatically when the protocol-based VLAN is created. You can use the display
protocol-vlan vlan all command to display the protocol indexes. The protocol-index argument
ranges from 0 to 15.
to protocol-end: Specifies the end protocol index. The protocol-end argument must be greater than
or equal to the beginning protocol index. The protocol-end argument is in the range of 0 to 15.
all: Specifies all protocols bound to vlan-id.
Description
Use port hybrid protocol-vlan to associate the hybrid ports with a protocol-based VLAN.
Use undo port hybrid protocol-vlan to remove the association.
The configuration made in Layer 2 Ethernet interface view applies only to the port.
The configuration made in port group view applies to all ports in the port group.
Protocol Type
ipv4
ipv6
Protocol Type
ipv4
ipv6
Description
ID of the protocol-based VLAN bound to the port
Protocol template index
Protocol type specified by the protocol template
158
