Directory: In the Directory Structure field, you can select the root directory, parent
directory and child directory. When the parent directory is selected, you have the
option to use the Device Name, Device Number or Device IP for the name of the
directory; and when the Child Directory is selected, you can use the Camera Name or
Camera No. as the name of the directory.

Picture Filing Interval: For better picture/stillshot management, you can set the
picture filing interval from 1 day to 30 days. Pictures captured in the same time
interval will be saved in one folder named after the beginning date and ending date of
the time interval.

Picture Name: Set the naming rule for captured picture files. You can choose Default
in the drop-down list to use the default naming convention:
IP address_channel number_capture time_event type.jpg
(e.g., 10.11.37.189_01_20150917094425492_FACE_DETECTION.jpg).
Or you can customize it by adding a Custom Prefix to the default naming rule.
5. Check the Upload Picture checkbox to enable the function.

Upload Picture: To enable uploading the captured picture to the FTP server.

Anonymous Access to the FTP Server (user name and password not required on
login): Check the Anonymous checkbox to enable the anonymous access to the FTP
server.
NOTE: The anonymous access function must be supported by the FTP server.
6. Click Save to save the settings.

CONFIGURING EMAIL SETTINGS

Purpose:
The system can be configured to send an Email notification to all designated receivers if an alarm
event is detected, e.g., motion detection event, video loss, video tampering, etc...
Before you start:
Please configure the DNS Server settings under Configuration > Network > Basic Settings > TCP/IP
before using the Email function.
Steps:
1. Enter the TCP/IP Settings (Configuration > Network > Basic Settings > TCP/IP) to set the IPv4
Address, IPv4 Subnet Mask, IPv4 Default Gateway and the Preferred DNS Server.
NOTE: Please refer to
detailed information.
2. Enter the Email Settings interface: Configuration > Network >Advanced Settings > Email.
3. Configure the following settings:

Sender: The name of the email sender.

Sender's Address: The email address of the sender.

SMTP Server: IP address or host name (e.g., smtp.263xmail.com) of the SMTP Server.
10385 Westmoor Drive, Suite 210, Westminster, CO 80021 | www.3xlogic.com | (877) 3XLOGIC
Section 9.1 Configuring Basic Settings - Configuring TCP/IP Settings
USER MANUAL| VX-2S-CPIR-W
for
66
