5. Click the Add Server button (only available after selecting an applicable Server Group). This will launch
the Add/Edit Server form. VISIX V-Series devices (including the VX-2S-CPIR-W) are considered edge
recording devices, and thus are recognized as their own Server within the VIGIL suite, including VCM.
6. Check off VIGIL Camera. This will indicate to VCM that the device you are adding is a V-Series All-in-One
camera.
7. Check-off Use VIGIL Connect. Alternatively, if you wish to use traditional network connection criteria,
leave Use VIGIL Connect disabled and enter in IP/DNS Name and Port info (if using standard network
connection values, also ignore steps 8 and 9 of these instructions) for the device.
8. Enter the VIGIL Connect alias of the VX-2S-CPIR-W camera in the Serial No./Alias field.
9. After entering an alias, click Test VIGIL Connect to ensure successful communication with the VIGIL
Connect system.
10. Fill in all remaining required fields and click OK to add the camera to your list of centrally managed VIGIL
Servers/V-Series Cameras.
If you experience issues connecting to the VX-2S-CPIR-W Multi Sensor Camera in VCM, confirm the alias that has
been entered is correct. If all settings appear to be correct, contact 3xLOGIC for further instruction or reference
Tech Tip 140028 VIGIL Connect Troubleshoot Guide

ADDING A VX-2S-CPIR-W CAMERA TO 3XLOGIC VIEW LITE II MOBILE (ANDROID AND IOS)

Steps:
2. To interface a VX-2S-CPIR-W Multi-Sensor camera with 3xLOGIC's View Lite II mobile app, launch the View
Lite II app on your mobile device (Android OS is pictured in the below screenshot, however, the process is
identical in the iOS version).
3. Open the Options side menu and select Server Configuration. The Video Source list will display.
4. Select VIGIL Server. VISIX V-Series devices are considered edge recording devices, and thus are recognized
as their own VIGIL Server within View Lite II. The VIGIL Server window will now deploy. A menu of all VIGIL
Servers already interfaced with View Lite II will deploy.
10385 Westmoor Drive, Suite 210, Westminster, CO 80021 | www.3xlogic.com | (877) 3XLOGIC
for troubleshooting tips.
Opening Video Source Menu
Figure 4-3
