- Page 1 3xLOGIC VISIX Gen III Cameras User Interface Guide Ver. 1.0 / 2020.07 Simple. Scalable. Secure.
-
Page 2: Table Of Contents
Image Transfer Configuration Image Transfer Configuration Relay Out Configuration Relay Out Configuration Event Rules Configuration Event Rules Configuration Event Rules Configuration Event Rules Configuration Schedule Configuration Schedule Configuration Motion Detection Configuration Motion Detection Configuration www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 2... - Page 3 This device complies with WEEE For safety instructions, please refer to your camera's quick start guide, which features all safety information as well as steps for physical installation. docuemntation for indivudal cameras is available at www.3xlogic.com. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 3...
-
Page 4: Adding A Camera To Vigil Server
For VIGIL 11 series systems, click the Detect Cameras button to start the firmware installation are available in section 3xLOGIC Camera Setup Utility-B. For Pre 11 systems, launch the utility from Start>Program Files> VIGIL > VISIXIPUtility-B.exe. "Setup - System Setup - Firmware Update". -
Page 5: Adding A Visix Gen Iii Camera To Vigil Server
Substream box has not been toggled on). ▪ Stream Type: H264/H265 ▪ User: admin ▪ Password : Use the new password you configured earlier in this section. ▪ Sub Stream - Toggle this box to enable substream. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 5... -
Page 6: Viewing A Camera In Vigil Client
Viewing a Camera in VIGIL Client After adding a camera to VIGIL Server, 3xLOGIC recommends VIGIL Client for viewing live and playback. Client’s powerful tool set can be leveraged by users to thoroughy and quickly review camera footage and other data collected by a VIGIL Server. -
Page 7: 3Xlogic Camera Setup Utility-B
Setup Tools - 3xLOGIC Camera Setup Utility-B Standard usage of the 3xLOGIC Camera Setup Utility-B is detailed on this page. Run the 3xLOGIC Camera Setup Utility-B Change the port as necessary when the network type is set to STATIC. i. Download and install the latest version of the utility at www.3xlogic.com. -
Page 8: Main Screen - Change Password
Password change is required at initial connection when the camera is new from factory or when a factory reset has been performed. The password can be reset from the 3xLOGIC Camera Setup Utility-B, however, if the cameras browser UI is opened first, the user will be prompted on login to change the password. -
Page 9: Main Screen
Channel Select button. Select one of the camera's available streams to display it in the live viewer Refer to ‘Setup > Video & Audio > Video’ to cuztomize the Video Stream settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 9... - Page 10 Motion -This indicator shows the Motion event status. Event Alert Icon ( ) appears if ‘Motion Detection’ is activated. Motion record is enabled by default. Camera Time - Display the camera system's time. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 10...
-
Page 11: Video Configuration
Details Pane- When an item is selected from the menu, related items and settings will be visible in the Details pane. Setup Menu - A list of configurable settings and information. Click a menu link to view related content. Some settings are model- dependent and will only be accessible for applicable models. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 11... -
Page 12: Video Configuration
2592 x 1944 2560 x 1440 2304 x 1296 1920x1080 1280x720 800x600 640x480 704x480 252x240 704x576 352x288 2592 x 1944 2560 x 1440 2304 x 1296 1920x1080 1280x720 800x600 640x480 704x480 252x240 Frame Rate - Select the maximum Frame Rate (FPS). www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 12... -
Page 13: Video Configuration
VBR - To guarantee the designated quality, the bit rate of video stream is changed in this mode. Therefore, the frame rate of video is likely to varying when network traffic is changing. This category will only appear for some codecs. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 13... -
Page 14: Video Configuration
SVC-T On - The H.264, H.265 (HEVC) SVC (Scalable Video Coding) Extension is a video compression algorithm that enables effective and efficient transmission of video files over low bandwidth networks. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 14... -
Page 15: Osd Configuration
User Text - Output the TEXT entered by the user. Supports a maximum of 30 characters. PTZ - Display PTZ information. This field is only visible on models with hardwired PTZ functionality. Click Apply to save the above settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 15... -
Page 16: Region Of Interest Configuration
Activation - The Region of interest can be enabled or disabled here. Quality - Set the quality of the set ROI area. Click Save to save the current settings. Click 'Cancel' to return to the previous setting. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 16... -
Page 17: Audio Configuration
Currently only G.71 is supported. Volume - Set the Audio Volume from 0 to 10. Sample Rate - Select the Audio Sample Rate. Currently only 8000 Hz is supported. Click Save to save settings changes. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 17... -
Page 18: Smart Stream Rc Configuration
Dynamic GOP - Select dynamic GOP to enable dynamic p-frame limits for GOP. FPS Drop - Select to enable FPS drops when necessary meet image quality selection. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 18... -
Page 19: Setup - Video & Audio Setup
Trigger Event - Select the event that will trigger Smart ETC settings to activate. Motion / Alarm Input / Motion and Alarm Input event triggers are available. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 19... -
Page 20: Privacy Mask Configuration
Area - Select an area designation (Area1 ~ Area16) and draw the privacy area. Click Save to save the current settings. Click 'Cancel' to return to the previous setting. Click ‘Clear Area' to delete the selected Area. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 20... -
Page 21: Profile Configuration
Profile List - Displays information about available camera settings profiles. Click ‘Add’ to add a new profile using the current camera settings. Click ‘Delete' to delete selected item from the profile list. Click ‘Apply' to apply setings from the selected profile. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 21... -
Page 22: Camera Image Adjustment
Sharpness - Using this control, sharpness of image can be adjusted to meet your preference. Click Save to save the current settings. Click 'Cancel' to return to the previous settings. Click 'Default' to return settings to the factory defaults. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 22... -
Page 23: Camera Exposure Settings
AGC - Enable this function to enable Automatic Gain Control. Click Save to save the current settings. Click 'Cancel' to return to the previous settings. Click 'Default' to return settings to the factory defaults. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 23... -
Page 24: Camera Day & Night Settings
B / W Level - Set the Black and White Level threshold for switching change Day mode into Night mode when Day & Night mode is set to Auto. Click Save to save the current settings. Click 'Cancel' to return to the previous settings. Click 'Default' to return settings to the factory defaults. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 24... -
Page 25: Camera Backlight Settings
BLC (Back Light Compensation) - The BLC function can only be set when WDR is off. Click Save to save the current settings. Click 'Cancel' to return to the previous settings. Click 'Default' to return settings to the factory defaults. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 25... -
Page 26: Camera White Balance
RB Gain - The R/B gain can be set only when the White Balance Mode is set to Manual. Click Save to save the current settings. Click 'Cancel' to return to the previous settings. Click 'Default' to return settings to the factory defaults. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 26... -
Page 27: Camera Image Enhancement
Stabilizer - The Stabilizer function can be enabled or disabled. Click Save to save the current settings. Click 'Cancel' to return to the previous settings. Click 'Default' to return settings to the factory defaults. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 27... -
Page 28: Video Enhancement
Flickerless - Enable to enhance images experiencing flickering. Click Save to save the current settings. Click 'Cancel' to return to the previous settings. Click 'Default' to return settings to the factory defaults. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 28... -
Page 29: Network Status
This menu will show Network information for the camera. Settings are for reference only and cannot be configured from this screen. 3xLOGIc recommends edting camera IP and network info from the 3xLOGIC Camera Setup Utility-B or from Network Settings (detailed in the next page of this guide). -
Page 30: Network Settings
Network Type - Define network IP address type from the Static Mode for the fixed IP or the Dynamic Mode by the dynamic IP address. Dynamic is the default mode used on 3xLOGIC VISIX Cameras. If you select Static Mode, you must fill out IP Address, Subnet Mask, Gateway, DNS Server and all ports. -
Page 31: Setup - Network Setup
General Setting - The Auto IP Setting function can be enabled or disabled here. Auto IP Settings Information - Displays the unique id or Auto IP address. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 31... -
Page 32: Onvif Settings
WS - Usertoken + Digest: Allows access with WS-User Token and Digest of ONVIF authentication. Discovery Mode - The ONVIF discovery function can be enabled or disabled. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 32... -
Page 33: Upnp Settings
(/ ~ ! $^ ( ) { } [ ] ; , ) cannot be used. ▪ ('@', '.', '_' ,'-', ' ') can be used. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 33... -
Page 34: Ddns Settings
If you setup DDNS properly, the IP address of your camera will be updated automatically whenever the IP address is changed or the system is rebooted. If IP updating to DDNS site is failed, the camera will keep retrying in 1min. intervals. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 34... -
Page 35: Ftp Settings
Password - Enter a Password to access to the FTP Server. Fill out using the correct Password registered in the FTP Server. Click Apply to save new settings. Refer the above screen image for the example. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 35... -
Page 36: Smtp Settings
The title of the Email is limited to 40 characters including the spaces. Message - Define the contents of E-Mail when camera sends an E-mail. The message of the Email is limited to 40 characters including the spaces. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 36... -
Page 37: Snmp Settings
Private-Key Password - Information protection password is a private encrypted password. A minimum of 8 digits required and a maximum of up to 30 digits allowed. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 37... -
Page 38: Rtsp Information
It is possible to set each RTP Multicast for Stream 1-3 (main, sub, third). Click Apply to save new settings. Click this button between configruing the different channels or data will not be saved for the preceding channel settings. RTSP Connection information. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 38... -
Page 39: Action Rules Configuration
Action rules List - This indicates the custom action rule information added to the Action rules list. Click Add to add custom action rules. Click ‘Modify' to modify a selected item from the action rules list. Click 'Delete' to delete a selected item from the action rules list. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 39... -
Page 40: Action Rules Add / Modify
Action1 ~ Action5 - Select the action to take if the event occurs. Recording, FTP Recipient, SMTP Recipient and Relay Out are available. Click Save to save the current settings. Click 'Cancel' to return to the previous menu. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 40... -
Page 41: Image Transfer Configuration
Define Number of image transferred per second. Pre-alarm Duration Define duration of image transfer before an event. Post-alarm Duration Define duration of image transfer after an event. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 41... -
Page 42: Relay Out Configuration
Idle State - Select whether the contact is normally opened or is closed. Duration - The relay will remain trigger during the set time. If bistable mode is selected, this function is activated Click Apply to save the new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 42... -
Page 43: Event Rules Configuration
Event Rules List - Event Rule information for added event rules is displayed here. Click ‘Add’ to add custom event rules. Click ‘Modify' to modify a selected item from the event rules list. Click 'Delete' to delete a selected item from the event rules list. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 43... -
Page 44: Event Rules Configuration
Rules - Select the action rule defined in the Trigger Action-Action rule menu. Click Save to save the current settings. Click 'Cancel' to return to the previous setting. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 44... -
Page 45: Schedule Configuration
Setup - Event Setup Schedule Configuration Mode - The Schedule function can be enabled or disabled here. Repeat Rule - If desired, set a recurring time the event occurs. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 45... -
Page 46: Motion Detection Configuration
If a High value is selected, it will detect very small motions while conversely, it becomes insensitive to motion when a Low value is selected. Click Save to save the current settings. Click 'Cancel' to return to the previous settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 46... -
Page 47: Temperature
Mode - Select either Fahrenheit and Celsius. Threshold - Define the temperature at which the event trigger occurs Temperature - Indicates the current temperature of the IP camera. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 47... -
Page 48: Alarm Configuration
Input Device Setup - Select input device type from OFF / N.O. / N.C. Operation Ignore this input sensor. The contact is normally open and closed when activated. The contact is normally closed and open when activated. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 48... -
Page 49: Record Management
Target Stream - Select the channel you want to record video from. Click Save to save the current settings. Recording List - Display the information about the recording settings. Click ‘Modify’ to modify the selected item in the recording list. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 49... -
Page 50: Record Configuration
Pre Duration - Define duration of pre-recording before an event. Post Duration - Define duration of post-recording image transfer after an event. Click Save to save the current settings. Click 'Cancel' to return to the previous setting. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 50... -
Page 51: Recording List
When playing back recorded MP4 file format with H.265 (HEVC) codec, video may not play due to the performance issues with the VLC plug-in. 3xLOGIC recommends always recording and reviewing video via the VIGIL VMS. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com... -
Page 52: Setup - Record Setup
Recording Video Viewer - Play the recorded video. Recording Video Information - Display the information about the recorded video. Click 'Replay' to view the recorded video again. Click 'Back' to return to the previous menu. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 52... -
Page 53: Storage Configuration
Setup - Record Setup Storage Configuration Display the SD card information mounted from device. When you select the item in the storage list, you can set the functions related to the SD card here. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 53... -
Page 54: Storage Configuration
Format - Delete the all contents that are stored in SD card and format. Click Apply to save new settings. Click 'Cancel' to return to the previous settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 54... -
Page 55: Ip Address Filter Configuration
IP Address - Define the IP address you want to apply the IP filter to. Click ‘Add’ to add the IP address to the filter list. Click ‘Remove’ to remove the IP address selected in the list. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 55... -
Page 56: Rtsp Authentication Configuration
VISIX Cameras, RTSP Streams may be required. Always disable RTSP Authetnication in this case before entering the RTSP URL for the cameras in the VIGIL Server Network Camera settings. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 56... -
Page 57: Ieee 802.1X Configuration
Verify - Verify Password. CA Certificate - Select the CA certificate required for TLS, TTLS, and PEAP authentication. Certificate - Select the client certificate required for TLS authentication Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 57... -
Page 58: Https Configuration
- WEB : “HTTP” “HTTPS” “HTTP and HTTPS” - ONVIF, RTSP OVER HTTP : “HTTP” “HTTPS” “HTTP and HTTPS” Click Apply to save new settings. When HTTPS mode is chosen, input https://<IP Address> to connect to the camera. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 58... - Page 59 CA Certificate - Shows the installed CA certificates. Install CA Certificate - Install Certification. See the Details page. Properties - Shows information about the selected certificate. Delete - Delete the selected CA certificate. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 59...
-
Page 60: Certificates Configuration
Certificate Name - Enter a unique name to identify CA certificate. Select File - Choose CA certification file OK - Request installing CA certificate. Cancel - Cancel install CA certificate and return back to certificates configuration. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 60... -
Page 61: Service Configuration
Setup - Security Setup Service Configuration SSH - The SSH function can be enabled or disabled here. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 61... -
Page 62: System Information
Setup - System Setup System Information System Information is displayed here. Device Name - Enter the device name. Location - Shows camera's location. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 62... -
Page 63: System Diagnostics
Shows Uptime, SD card, NAND, EEPROM, Audio chip, Important file system and NTP Status. Warning: If the camera is abnormally terminated, a download button will appear on the diagnostics page to download a file that allows you to check the error information log. . www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 63... -
Page 64: Firmware Update
If updating is finished, the system will be rebooted automatically. 2. Please make sure to check the ‘Notice’ shown on screen. If firmware update is completed, the camera will reboot automatically and ‘Setup window’ will be closed. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 64... -
Page 65: Date & Time Settings
Synchronize with time server (NTP) - Choose time server available to connect to the camera. Date & Time will be updated automatically every hour when connected. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 65... -
Page 66: Dst Settings
General Setting - DST function can be enabled or disabled here. Date&Time Settings - Set the Start time and end time for DST. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 66... -
Page 67: Users Management
Click 'Cancel' to return to the previous menu. Modify - Modify user account info. For the admin account, only password function can be modified. Delete - Delete the selected user account. Admin account cannot be deleted. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 67... -
Page 68: System Log
Filter - Select a date, time, sort or type of log to filter the log. Click the 'Refresh' button to refresh the log list. Click 'Filter' to view the filtered log. System Log List - The filtered log is displayed. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 68... -
Page 69: Language
Setup - System Setup Language Language - Select the language for the camera interface from the menu. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 69... -
Page 70: Factory Reset
Except Network Settings and User Settings - Reset all setting to defaults except network and user settings. ▪ Only Camera Settings - Reset only camera related settings to their factory defaults. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 70... -
Page 71: Restart
Setup - System Setup Restart If you click the ‘RESTART’ menu, a message box will be shown to confirm a camera system restart. Click the ‘OK’ button to restart. You will be logged out and will require a relogin to continue setup and settings configuration. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 71... -
Page 72: System Open Source License
Setup - System Setup System Open Source License This menu will show you all the list of System Open Source Licensees used in the camera. Open Source Name / Version / License is displayed. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 72... -
Page 73: Ptz Settings
- AutoFlip : This is a function that enables continuous pan by converting PTZ to 180 degree panoraamic instantly. - Digital Zoom : Enable this to allow Digital zoom. Click Apply to save new settings. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com Pg. 73... - Page 74 Simple. Scalable. Secure. www.3xlogic.com | 877 3xLOGIC | helpdesk@3xlogic.com...
