SETTING A PRESET

Steps:
1. In the PTZ control panel, select a preset number from the preset list.
2. Use the PTZ control buttons to aim the camera toward the desired position.
a. Pan the camera to the right or left.
b. Tilt the camera up or down.
c. Zoom in or out.
d. Refocus the lens.
3. Click to save the current camera position to the selected preset.
4. You can click to delete the preset.
NOTE: You can configure up to 128 presets.

CALLING A PRESET

This feature enables the camera to point to a specified preset scene manually or when an event takes
place.
10385 Westmoor Drive, Suite 210, Westminster, CO 80021 | www.3xlogic.com | (877) 3XLOGIC
One-touch focus
Initialize lens
Adjust speed of pan/tilt movements
Adjust speed of pan/tilt movements
Start Manual Tracking
Start 3D Zoom
Table 5-2 Descriptions of PTZ Control Panel
Setting a Preset
Figure 7-4
