| Class of Service Commands
C 34
HAPTER
Priority Commands (Layer 2)
switchport priority
default
E
XAMPLE
The following example shows how to assign round-robin weights of 1 - 4 to
the CoS priority queues 0 - 3.
Console(config)#queue weight 1 2 3 4
Console(config)#
R C
ELATED OMMANDS
queue mode (858)
show queue weight (861)
This command sets a priority for incoming untagged frames. Use the no
form to restore the default value.
S
YNTAX
switchport priority default default-priority-id
no switchport priority default
default-priority-id - The priority number for untagged ingress traffic.
The priority is a number from 0 to 7. Seven is the highest priority.
D S
EFAULT ETTING
The priority is not set, and the default value for untagged frames received
on the interface is zero.
C M
OMMAND ODE
Interface Configuration (Ethernet, Port Channel)
C U
OMMAND SAGE
The precedence for priority mapping is IP DSCP, and then default
◆
switchport priority.
The default priority applies for an untagged frame received on a port
◆
set to accept all frame types (i.e, receives both untagged and tagged
frames). This priority does not apply to IEEE 802.1Q VLAN tagged
frames. If the incoming frame is an IEEE 802.1Q VLAN tagged frame,
the IEEE 802.1p User Priority bits will be used.
The switch provides four priority queues for each port. It can be
◆
configured to use strict priority queuing, WRR, or a combination of
strict and weighted queuing using the
frames that do not have VLAN tags are tagged with the input port's
default ingress user priority, and then placed in the appropriate priority
queue at the output port. The default priority for all ingress ports is
zero. Therefore, any inbound frames that do not have priority tags will
be placed in queue 1 of the output port. (Note that if the output port is
an untagged member of the associated VLAN, these frames are
stripped of all VLAN tags prior to transmission.)
– 860 –
queue mode command. Inbound
