ECS4510-28F
Installation Guide
28-Port Layer 2
Gigabit Ethernet Switch
www.edge-core.com

Advertisement

Table of Contents
loading

Related Manuals for Edge-Core ecs4510-28f

Summary of Contents for Edge-Core ecs4510-28f

  • Page 1 ECS4510-28F Installation Guide 28-Port Layer 2 Gigabit Ethernet Switch www.edge-core.com...
  • Page 3 NSTALLATION UIDE ECS4510-28F G IGABIT THERNET WITCH Layer 2 Switch with 22 100/1000BASE-X SFP Ports, 2 Combination Gigabit (RJ-45/SFP) Ports, 2 10G SFP+ Ports, and 1 10G Dual-Port Extender Module Slot ECS4510-28F E102012-CS-R01 150200000437A...

  • Page 5: Compliances And Safety Statements

    OMPLIANCES AND AFETY TATEMENTS FCC - C LASS This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 6 OMPLIANCES AND AFETY TATEMENTS CE M (EEC) ECLARATION OF ONFORMANCE FOR AFETY This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/ 68/EEC.
  • Page 7 OMPLIANCES AND AFETY TATEMENTS AFETY OMPLIANCE Warning: Fiber Optic Port Safety When using a fiber optic port, never look at the transmit laser while it is powered on. Also, never look directly at the fiber TX port and fiber CLASS I cable ends when they are powered on.
  • Page 8 OMPLIANCES AND AFETY TATEMENTS OWER AFETY Please read the following safety information carefully before installing the switch: Installation and removal of the unit must be carried out by qualified WARNING: personnel only. The unit must be connected to an earthed (grounded) outlet to comply with ◆...
  • Page 9 OMPLIANCES AND AFETY TATEMENTS Power Cord Set U.S.A. and Canada The cord set must be UL-approved and CSA certified. The minimum specifications for the flexible cord are: - No. 18 AWG - not longer than 2 meters, or 16 AWG. - Type SV or SJ - 3-conductor The cord set must have a rated current capacity of at least 10 A...
  • Page 10 OMPLIANCES AND AFETY TATEMENTS La prise secteur doit se trouver à proximité de l’appareil et son accès doit ◆ être facile. Vous ne pouvez mettre l’appareil hors circuit qu’en débranchant son cordon électrique au niveau de cette prise. L’appareil fonctionne à une tension extrêmement basse de sécurité qui est ◆...
  • Page 11 OMPLIANCES AND AFETY TATEMENTS Bitte unbedingt vor dem Einbauen des Switches die folgenden Sicherheitsanweisungen durchlesen: Die Installation und der Ausbau des Geräts darf nur durch WARNUNG: Fachpersonal erfolgen. Das Gerät sollte nicht an eine ungeerdete Wechselstromsteckdose ◆ angeschlossen werden. Das Gerät muß an eine geerdete Steckdose angeschlossen werden, welche ◆...
  • Page 12 OMPLIANCES AND AFETY TATEMENTS ARNINGS AND AUTIONARY ESSAGES This product does not contain any serviceable user parts. ARNING Installation and removal of the unit must be carried out by ARNING qualified personnel only. When connecting this device to a power outlet, connect the ARNING field ground lead on the tri-pole power plug to a valid earth ground line to prevent electrical hazards.
  • Page 13 OMPLIANCES AND AFETY TATEMENTS ND OF RODUCT This product is manufactured in such a way as to allow for the recovery and disposal of all included electrical components once the product has reached the end of its life. ANUFACTURING ATERIALS There are no hazardous nor ozone-depleting materials in this product.
  • Page 14 OMPLIANCES AND AFETY TATEMENTS – 14 –...

  • Page 15: About This Guide

    BOUT UIDE URPOSE This guide details the hardware features of the switch, including the physical and performance-related characteristics, and how to install the switch. UDIENCE The guide is intended for use by network administrators who are responsible for installing and setting up network equipment; consequently, it assumes a basic working knowledge of LANs (Local Area Networks).
  • Page 16 BOUT UIDE EVISION ISTORY This section summarizes the changes in each revision of this guide. 2012 R EPTEMBER EVISION This is the first revision of this guide. – 16 –...

  • Page 17: Table Of Contents

    ONTENTS OMPLIANCES AND AFETY TATEMENTS BOUT UIDE ONTENTS ABLES IGURES NTRODUCTION Overview Description of Hardware ETWORK LANNING Introduction to Switching Application Examples Application Notes NSTALLING THE WITCH Selecting a Site Ethernet Cabling Equipment Checklist Mounting Installing an Optional SFP/SFP+ Transceiver Grounding the Switch Connecting to a Power Source Connecting to the Console Port...
  • Page 18 ONTENTS Twisted-Pair Devices Fiber Optic SFP Devices 10 Gbps Fiber Optic Connections Connectivity Rules Cable Labeling and Connection Records ROUBLESHOOTING Diagnosing Switch Indicators Power and Cooling Problems Installation In-Band Access ABLES Twisted-Pair Cable and Pin Assignments Fiber Standards PECIFICATIONS Physical Characteristics Switch Features Management Features Standards...

  • Page 19: Tables

    ABLES Table 1: SFP Port (1~24) and SFP+ Port (25~28) Status LEDs Table 2: 10/100/1000 Mbps RJ-45 Ports Status LEDs (23~24) Table 3: System Status LEDs Table 4: Serial Converter Wiring Table 5: Maximum 10GBASE-SR 10 Gigabit Ethernet Cable Lengths Table 6: Maximum 10GBASE-LR 10 Gigabit Ethernet Cable Length Table 7:...
  • Page 20 ABLES – 20 –...

  • Page 21: Figures

    IGURES Figure 1: Front Panel Figure 2: Rear Panel Figure 3: Side Panel Figure 4: Port and System LEDs Figure 5: Power Supply Socket Figure 6: Network Aggregation Plan Figure 7: Remote Connections with Fiber Cable Figure 8: Making VLAN Connections Figure 9: RJ-45 Connections Figure 10:...
  • Page 22 IGURES – 22 –...

  • Page 23: Introduction

    NTRODUCTION VERVIEW The ECS4510-28F is an intelligent Layer 2 switch with 24 100/1000BASE-X SFP transceiver slots, two combination ports, comprised of two RJ-45 ports and two SFP+ transceiver slots, two 10G SFP+ slots, and one 10G dual-port extender module slot.

  • Page 24: Figure 2: Rear Panel

    | Introduction HAPTER Overview Figure 2: Rear Panel Grounding Points DB-25 RPS Socket Power Socket Extender Module Figure 3: Side Panel Cooling Fans WITCH RCHITECTURE This Gigabit Ethernet switch employs a wire-speed, non-blocking switching fabric. This permits simultaneous wire-speed transport of multiple packets at low latency on all ports.

  • Page 25: Description Of Hardware

    | Introduction HAPTER Description of Hardware ETWORK ANAGEMENT PTIONS With a comprehensive array of LEDs, the switch provides “at a glance” monitoring of network and port status. The switch can be managed over the network with a web browser or Telnet application, or via a direct connection to the console port.
  • Page 26 | Introduction HAPTER Description of Hardware SFP T RANSCEIVER LOTS The switch contains 24 Small Form Factor Pluggable (SFP) transceiver slots that operate at 1000 Mbps full duplex. These slots support 1000 Mbps SFP Gigabit Ethernet transceivers and 100 Mbps Fast Ethernet trasceivers.. For information on the recommended standards for fiber optic cabling, see “1000 Mbps Gigabit Ethernet Collision Domain”...

  • Page 27: Table 1: Sfp Port (1~24) And Sfp+ Port (25~28) Status Leds

    | Introduction HAPTER Description of Hardware ORT AND YSTEM TATUS The switch includes a display panel for key system and port indications that simplify installation and network troubleshooting. The LEDs, which are located on the front panel for easy viewing, are shown below and described in the following tables.

  • Page 28: Table 3: System Status Leds

    | Introduction HAPTER Description of Hardware Table 3: System Status LEDs Condition Status Power On Green The unit’s internal power supply is operating normally. On Amber The unit has an internal power supply fault. The unit has no power connected. Diag On Green The system diagnostic test has completed...

  • Page 29: Network Planning

    ETWORK LANNING NTRODUCTION TO WITCHING A network switch allows simultaneous transmission of multiple packets via non- crossbar switching. This means that it can partition a network more efficiently than bridges or routers. The switch has, therefore, been recognized as one of the most important building blocks for today’s networking technology.

  • Page 30: Application Examples

    | Network Planning HAPTER Application Examples PPLICATION XAMPLES The switch is not only designed to segment your network, but also to provide a wide range of options in setting up network connections. Some typical applications are described below. ETWORK GGREGATION With 28 parallel bridging ports (i.e., 28 distinct collision domains), the switch can collapse a complex network down into a single efficient bridged node, increasing overall bandwidth and throughput.

  • Page 31: Figure 7: Remote Connections With Fiber Cable

    | Network Planning HAPTER Application Examples EMOTE ONNECTIONS WITH IBER ABLE Fiber optic technology allows for longer cabling than any other media type. A 1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a 1000BASE-LX (SMF) link up to 10 km, and a 1000BASE-ZX link up to 100 km. This allows the switch to serve as a collapsed backbone, providing direct connectivity for a widespread LAN.

  • Page 32: Figure 8: Making Vlan Connections

    | Network Planning HAPTER Application Examples VLAN C AKING ONNECTIONS This switch supports VLANs which can be used to organize any group of network nodes into separate broadcast domains. VLANs confine broadcast traffic to the originating group, and can eliminate broadcast storms in large networks. This provides a more secure and cleaner network environment.

  • Page 33: Application Notes

    | Network Planning HAPTER Application Notes PPLICATION OTES Full-duplex operation only applies to point-to-point access (such as when a switch is attached to a workstation, server or another switch). When the switch is connected to a hub, both devices must operate in half-duplex mode.
  • Page 34 | Network Planning HAPTER Application Notes – 34 –...

  • Page 35: Installing The Switch

    NSTALLING THE WITCH ELECTING A Switch units can be mounted in a standard 19-inch equipment rack or on a flat surface. Be sure to follow the guidelines below when choosing a location. The site should: ◆ be at the center of all the devices you want to link and near a power ■...

  • Page 36: Ethernet Cabling

    | Installing the Switch HAPTER Ethernet Cabling THERNET ABLING To ensure proper operation when installing the switch into a network, make sure that the current cables are suitable for 10BASE-T, 100BASE-TX or 1000BASE-T operation. Check the following criteria against the current installation of your network: Cable type: Unshielded twisted pair (UTP) or shielded twisted pair (STP) ◆...

  • Page 37: Equipment Checklist

    After unpacking this switch, check the contents to be sure you have received all the components. Then, before beginning the installation, be sure you have all other necessary installation equipment. ACKAGE ONTENTS Gigabit Ethernet Switch (ECS4510-28F) ◆ Power Cord—either US, Continental Europe or UK ◆ Two rack-mounting brackets and eight screws ◆...

  • Page 38: Mounting

    | Installing the Switch HAPTER Mounting OUNTING This switch can be mounted in a standard 19-inch equipment rack or on a desktop or shelf. Mounting instructions for each type of site follow. OUNTING Before rack mounting the switch, pay particular attention to the following factors: Temperature: Since the temperature within a rack assembly may be higher ◆...

  • Page 39: Figure 10: Attaching The Brackets

    | Installing the Switch HAPTER Mounting Figure 10: Attaching the Brackets Mount the device in the rack, using four rack-mounting screws (not provided). Be sure to secure the lower rack-mounting screws first to prevent the brackets being bent by the weight of the switch. –...

  • Page 40: Figure 11: Installing The Switch In A Rack

    | Installing the Switch HAPTER Mounting Figure 11: Installing the Switch in a Rack If installing a single switch only, turn to “Connecting to a Power Source” on page If installing multiple switches, mount them in the rack, one below the other, in any order.

  • Page 41: Installing An Optional Sfp/Sfp+ Transceiver

    | Installing the Switch HAPTER Installing an Optional SFP/SFP+ Transceiver SFP/SFP+ T NSTALLING AN PTIONAL RANSCEIVER The SFP slots support the following optional SFP transceivers: 1000BASE-SX (ET4201-SX) ◆ 1000BASE-LX (ET4201-LX) ◆ 1000BASE-ZX (ET4201-ZX) ◆ Figure 12: Inserting an SFP Transceiver into a Slot The SFP+ slots support the following optional SFP+ transceivers: 10GBASE-SR (ET5402-SR) ◆...

  • Page 42: Grounding The Switch

    | Installing the Switch HAPTER Grounding the Switch Slide the SFP transceiver into the slot until it clicks into place. SFP transceivers are hot-swappable. The switch does not need to be powered off before installing or removing a transceiver. However, always first disconnect the network cable before removing a transceiver.

  • Page 43: Connecting To A Power Source

    | Installing the Switch HAPTER Connecting to a Power Source Figure 13: Grounding Point Grounding Points ONNECTING TO A OWER OURCE To connect a switch to a power source: Insert the power cable plug directly into the AC socket located at the back of the switch.

  • Page 44: Connecting To The Console Port

    | Installing the Switch HAPTER Connecting to the Console Port Check the front-panel LEDs as the device is powered on to be sure the Power LED is lit. If not, check that the power cable is correctly plugged in. ONNECTING TO THE ONSOLE This port is used to connect a console device to the switch through a straight- through UTP cable and an RJ-45-to-DB-9 serial converter.
  • Page 45 | Installing the Switch HAPTER Connecting to the Console Port The serial port’s configuration requirements are as follows: Default Baud rate—115,200 bps ◆ Character Size—8 Characters ◆ Parity—None ◆ Stop bit—One ◆ Data bits—8 ◆ Flow control—none ◆ – 45 –...
  • Page 46 | Installing the Switch HAPTER Connecting to the Console Port – 46 –...

  • Page 47: Making Network Connections

    AKING ETWORK ONNECTIONS ONNECTING ETWORK EVICES The switch is designed to be connected remote devices using optional SFP transceivers. It may also be connected to 10, 100, or 1000 Mbps network cards in PCs and servers, as well as to other switches and hubs. WISTED EVICES Each device requires an unshielded twisted-pair (UTP) cable with RJ-45...

  • Page 48: Figure 16: Making Twisted-Pair Connections

    | Making Network Connections HAPTER Twisted-Pair Devices ONNECTING TO ERVERS UBS AND WITCHES Attach one end of a twisted-pair cable segment to the device’s RJ-45 connector. Figure 16: Making Twisted-Pair Connections If the device is a network card and the switch is in the wiring closet, attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet.

  • Page 49: Fiber Optic Sfp Devices

    | Making Network Connections HAPTER Fiber Optic SFP Devices SFP D IBER PTIC EVICES An optional Gigabit SFP transceiver (1000BASE-SX, 1000BASE-LX, 1000BASE- ZX) can be used for a backbone connection between switches, or for connecting to a high-speed server. Each single-mode fiber port requires 9/125 micron single-mode fiber optic cable with an LC connector at both ends.

  • Page 50: Figure 17: Making Fiber Port Connections

    | Making Network Connections HAPTER Fiber Optic SFP Devices Figure 17: Making Fiber Port Connections As a connection is made, check the Link LED on the switch corresponding to the port to be sure that the connection is valid. The SFP fiber optic ports operate at 1 Gbps, full duplex, with auto-negotiation of flow control.

  • Page 51: Gbps Fiber Optic Connections

    | Making Network Connections HAPTER 10 Gbps Fiber Optic Connections 10 G IBER PTIC ONNECTIONS An optional 10 Gigabit transceiver (SFP+) can be used for a backbone connection between switches. Single-mode fiber ports require 9/125 micron single-mode fiber optic cable. Multimode fiber optic ports require 50/125 or 62.5/125 micron multimode fiber optic cable.

  • Page 52: Connectivity Rules

    | Making Network Connections HAPTER Connectivity Rules ONNECTIVITY ULES When adding hubs (repeaters) to your network, please follow the connectivity rules listed in the manuals for these products. However, note that because switches break up the path for connected devices into separate collision domains, you should not include the switch or connected cabling in your calculations for cascade length involving other devices.

  • Page 53: Table 7: Maximum 10Gbase-Er 10 Gigabit Ethernet Cable Length

    | Making Network Connections HAPTER Connectivity Rules Table 7: Maximum 10GBASE-ER 10 Gigabit Ethernet Cable Length Fiber Size Fiber Bandwidth Maximum Cable Length Connector 9/125 micron single- 40 km (24.85 miles) mode fiber 1000 M IGABIT THERNET OLLISION OMAIN Table 8: Maximum 1000BASE-T Gigabit Ethernet Cable Length Cable Type Maximum Cable Length Connector...

  • Page 54: Cable Labeling And Connection Records

    | Making Network Connections HAPTER Cable Labeling and Connection Records 100 M THERNET OLLISION OMAIN Table 12: Maximum Fast Ethernet Cable Lengths Type Cable Type Max. Cable Length Connector 100BASE-TX Category 5 or better 100-ohm 100 m (328 ft) RJ-45 UTP or STP 10 M THERNET...
  • Page 55 | Making Network Connections HAPTER Cable Labeling and Connection Records Label each separate piece of equipment. ◆ Display a copy of your equipment map, including keys to all abbreviations at ◆ each equipment rack. – 55 –...
  • Page 56 | Making Network Connections HAPTER Cable Labeling and Connection Records – 56 –...

  • Page 57: Diagnosing Switch Indicators

    ROUBLESHOOTING IAGNOSING WITCH NDICATORS Table 14: Troubleshooting Chart Symptom Action Power LED is Off ◆ Check connections between the switch, the power cord and the wall outlet. ◆ Contact your dealer for assistance. Power LED is on ◆ Contact your local dealer for assistance. Amber Diag LED On Amber ◆...

  • Page 58: Troubleshooting

    | Troubleshooting PPENDIX Power and Cooling Problems OWER AND OOLING ROBLEMS If the power indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply.

  • Page 59: Cables

    ABLES WISTED ABLE AND SSIGNMENTS For 10/100BASE-TX connections, the twisted-pair cable must have two pairs of wires. For 1000BASE-T connections the twisted-pair cable must have four pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes.

  • Page 60: Table 15: 10/100Base-Tx Mdi And Mdi-X Port Pinouts

    | Cables PPENDIX Twisted-Pair Cable and Pin Assignments 10BASE-T/100BASE-TX P SSIGNMENTS Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for RJ-45 connections: 100-ohm Category 3 or better cable for 10 Mbps connections, or 100-ohm Category 5 or better cable for 100 Mbps connections. Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet).

  • Page 61: Figure 19: Straight-Through Wiring

    | Cables PPENDIX Twisted-Pair Cable and Pin Assignments Figure 19: Straight-through Wiring EIA/TIA 568B RJ-45 Wiring Standard 10/100BASE-TX Straight-through Cable White/Orange Stripe Orange White/Green Stripe End A End B Blue White/Blue Stripe Green White/Brown Stripe Brown ROSSOVER IRING If the twisted-pair cable is to join two ports and either both ports are labeled with an “X”...

  • Page 62: Table 16: 1000Base-T Mdi And Mdi-X Port Pinouts

    | Cables PPENDIX Twisted-Pair Cable and Pin Assignments 1000BASE-T P SSIGNMENTS All 1000BASE-T ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. The table below shows the 1000BASE-T MDI and MDI-X port pinouts. These ports require that all four pairs of wires be connected.

  • Page 63: Fiber Standards

    | Cables PPENDIX Fiber Standards 1000BASE-T DJUSTING XISTING ATEGORY ABLING TO If your existing Category 5 installation does not meet one of the test parameters for 1000BASE-T, there are basically three measures that can be applied to try and correct the problem: Replace any Category 5 patch cables with high-performance Category 5e or Category 6 cables.
  • Page 64 | Cables PPENDIX Fiber Standards Table 17: Fiber Standards (Continued) ITU-T Description Application Standard G.654 1550-nm Loss-Minimized Fiber Extended long-haul applications. Optimized for high-power Single-mode, 9/125-micron core transmission in the 1500 to 1600-nm region, with low loss in the 1550-nm band.

  • Page 65: Specifications

    PECIFICATIONS HYSICAL HARACTERISTICS ORTS 24 1000BASE-SFP, with auto-negotiation 2 10/100/1000BASE-T, shared with two SFP transceiver slots ETWORK NTERFACE Ports 1-24: SFP connector Shared Ports 1-2: RJ-45 connector, auto MDI/X 10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better) 100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better) 1000BASE-T: RJ-45 (100-ohm, UTP or STP cable;...
  • Page 66 | Specifications PPENDIX Physical Characteristics EIGHT 3.8 kg (8.38 lbs) (W x D x H): 440 x 315 x 44 mm (17.32 x 12.4 x 1.73 inches) EMPERATURE Operating: 0°C to 45°C (32°F to 113°F) Storage: -40°C to 70°C (-40°F to 158°F) UMIDITY Operating: 10% to 90% (non-condensing) AC I...

  • Page 67: Switch Features

    | Specifications PPENDIX Switch Features WITCH EATURES ORWARDING Store-and-forward HROUGHPUT Wire speed ONTROL Full Duplex: IEEE 802.3x Half Duplex: Back pressure ANAGEMENT EATURES ANAGEMENT SSH, Telnet, SNMP, or HTTP ANAGEMENT RS-232 RJ-45 console port OFTWARE OADING HTTP, TFTP in-band, or XModem out-of-band –...

  • Page 68: Standards

    | Specifications PPENDIX Standards TANDARDS IEEE 802.3-2005 Ethernet, Fast Ethernet, Gigabit Ethernet Full-duplex flow control Link Aggregation Control Protocol IEEE 802.1D -2004 Spanning Tree Protocol Rapid Spanning Tree Protocol Multiple Spanning Tree Protocol ISO/IEC 8802-3 OMPLIANCES MISSIONS EN55022 (CISPR 22) Class A EN 61000-3-2/3 FCC Class A CE Mark...

  • Page 69: Glossary

    LOSSARY 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Ethernet over two pairs of Category 5 UTP cable. 1000BASE-LH Specification for long-haul Gigabit Ethernet over two strands of 9/125 micron core fiber cable.
  • Page 70 LOSSARY ANDWIDTH The difference between the highest and lowest frequencies available for network signals. Also synonymous with wire speed, the actual speed of the data transmission along the cable. OLLISION OMAIN Single CSMA/CD LAN segment. CSMA/CD CSMA/CD (Carrier Sense Multiple Access/Collision Detect) is the communication method employed by Ethernet, Fast Ethernet, and Gigabit Ethernet.
  • Page 71 LOSSARY IEEE Institute of Electrical and Electronic Engineers. IEEE 802.3 Defines carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications. IEEE 802.3 Defines CSMA/CD access method and physical layer specifications for 1000BASE-T Gigabit Ethernet. (Now incorporated in IEEE 802.3-2005.) IEEE 802.3 Defines CSMA/CD access method and physical layer specifications for 100BASE- TX Fast Ethernet.
  • Page 72 LOSSARY (MAC) EDIA CCESS ONTROL A portion of the networking protocol that governs access to the transmission medium, facilitating the exchange of data between network nodes. An acronym for Management Information Base. It is a set of database objects that contains information about the device. ODAL ANDWIDTH Bandwidth for multimode fiber is referred to as modal bandwidth because it...
  • Page 73 LOSSARY (UDP) ATAGRAM ROTOCOL provides a datagram mode for packet-switched communications. It uses IP as the underlying transport mechanism to provide access to IP-like services. UDP packets are delivered just like IP packets – connection-less datagrams that may be discarded before reaching their targets. UDP is useful when TCP would be too complex, too slow, or just unnecessary.
  • Page 74 LOSSARY – 74 –...

  • Page 75: Index

    NDEX UMERICS 10 Gbps connectivity rules desktop mounting 10 Mbps connectivity rules device connections 100 Mbps connectivity rules 1000 Mbps connectivity rules 1000BASE-LH fiber cable Lengths 1000BASE-LX fiber cable Lengths electrical interference, avoiding 1000BASE-SX fiber cable Lengths equipment checklist 1000BASE-T Ethernet connectivity rules pin assignments ports...
  • Page 76 NDEX specifications compliances management environmental agent power features standards out-of-band compliance SNMP IEEE web-based status LEDs mounting the switch surge suppressor, using in a rack switch architecture on a desktop or shelf multimode fiber optic cables Telnet troubleshooting network in-band access connections power and cooling problems examples...
  • Page 78 ECS4510-28F E102012-CS-R01 150200000437A...
