8 Electrical Installation

8.1.4 Relay Connection

To set relay output, see par. group 5-4* Relays.
8
Terminals for relay connection
(Frame sizes A1, A2 and A3).
Terminals for relay connection
(Frame sizes C1 and C2).
156
No. 01 - 02
01 - 03
04 - 05
04 - 06
Terminals for relay connection
(Frame sizes A5, B1 and B2).
MG.33.BC.02 - VLT ® is a registered Danfoss trademark
FC 300 Design Guide
NB!
In motors without phase insulation paper or other in-
sulation reinforcement suitable for operation with volt-
age supply (such as a frequency converter), fit a Sine-
wave filter on the output of the frequency converter.
make (normally open)
break (normally closed)
make (normally open)
break (normally closed)
