Danfoss FC 300 Design Manual page 18

3 Introduction to AutomationDrive FC 300
Frame size D1
3
Enclosure IP
protection NEMA
High overload rated 90-110 kW at 400 V
power - 160% over- (380-500 V)
load torque 37-132 kW at 690 V
(525-690 V)
Frame size E1
Enclosure IP
protection NEMA
High overload rated 250-400 kW at 400 V
power - 160% over- (380-500 V)
load torque 355-560 kW at 690 V
(525-690 V)
NB!
The F frames have four different sizes, F1, F2, F3 and F4 The F1 and F2 consist of an inverter cabinet on the right and rectifier cabinet
on the left. The F3 and F4 have an additional options cabinet left of the rectifier cabinet. The F3 is an F1 with an additional options
cabinet. The F4 is an F2 with an additional options cabinet.
18
D2
21/54 21/54
Type 1/ Type 12 Type 1/ Type 12
132-200 kW at 400 V
(380-500 V)
160-315 kW at 690 V
(525-690 V)
E2
21/54
Type 1/ Type 12 Chassis
250-400 kW at 400 V
(380-500 V)
355-560 kW at 690 V
(525-690 V)
MG.33.BC.02 - VLT
D3
00
Chassis
90-110 kW at 400 V
(380-500 V)
37-132 kW at 690 V
(525-690 V)
F1/F3
00 21/54
Type 1/ Type 12
450 - 630 kW at 400 V
(380 - 500 V)
630 - 800 kW at 690 V
(525-690 V)
® is a registered Danfoss trademark
FC 300 Design Guide
D4
00
Chassis
132-200 kW at 400 V
(380-500 V)
160-315 kW at 690 V
(525-690 V)
F2/ F4
21/54
Type 1/ Type 12
710 - 800 kW at 400 V
(380 - 500 V)
900 - 1000 kW at 690 V
(525-690 V)
