FC 300 Design Guide

10.3 Encoder Option MCB 102

The encoder module can be used as feedback source for closed loop Flux control (par. 1-02
Speed PID Feedback Source
control (par. 7-00
Used for:
plus
• VVC closed loop
• Flux Vector Speed control
• Flux Vector Torque control
• Permanent magnet motor
Supported encoder types:
Incremental encoder: 5 V TTL type, RS422, max. frequency: 410 kHz
Incremental encoder: 1Vpp, sine-cosine
Hiperface® Encoder: Absolute and Sine-Cosine (Stegmann/SICK)
EnDat encoder: Absolute and Sine-Cosine (Heidenhain) Supports version 2.1
SSI encoder: Absolute
Encoder monitor:
The 4 encoder channels (A, B, Z, and D) are monitored, open and short circuit can be detected. There is a green LED for each channel which lights up
when the channel is OK.
NB!
The LEDs are only visible when removing the LCP. Reaction in case of an encoder error can be selected in par. 17-61
Monitoring
: None, Warning or Trip.
When the encoder option kit is ordered separately the kit includes:
• Encoder Option MCB 102
• Enlarged LCP fixture and enlarged terminal cover
The encoder option does not support AutomationDrive FC 302 frequency converters manufactured before week 50/2004.
Min. software version: 2.03 (par. 15-43
Connector Incremental SinCos Encoder
Designa- Encoder Hiperface®
tion (please refer to (please refer to
X31 Graphic A) Graphic B)
1 NC
2 NC 8 Vcc
3 5 VCC
4 GND
5 A input +COS
6 A inv input REFCOS
7 B input +SIN
8 B inv input REFSIN
9 Z input +Data RS485
10 Z inv input -Data RS485
11 NC NC
12 NC NC
Max. 5V on X31.5-12
* Supply for encoder: see data on encoder
). Configure encoder option in parameter group 17-xx
Software Version )
EnDat Encoder SSI Encoder
24 V*
5 Vcc 5 V*
GND GND
+COS
REFCOS
+SIN
REFSIN
Clock out Clock out
Clock out inv. Clock out inv.
Data in Data in
Data in inv. Data in inv.
MG.33.BC.02 - VLT ® is a registered Danfoss trademark
10 Options and Accessories
Flux Motor Feedback Source ) as well as closed loop speed
Description
24 V Output (21-25 V, I :125 mA)
max
8 V Output (7-12 V, I : 200 mA)
max
5 V Output (5 V ± 5%, I : 200 mA)
max
GND
A input
A inv input
B input
B inv input
Z input OR +Data RS485
Z input OR -Data RS485
Future use
Future use
Feedback Signal
