3 Introduction to AutomationDrive FC 300
3
Hand On
Auto
LCP Keys
Hand
Hand -> Off
Auto
Auto -> Off
All keys
All keys
The table shows under which conditions either the Local reference or the Remote reference is active. One of them is always active, but both can not be
active at the same time.
Configuration Mode
Par. 1-00
reference is active (see table above for the conditions).
Local Mode Configuration
Par. 1-05
24
par. 3-13 Reference Site
Linked to Hand / Auto
Linked to Hand / Auto
Linked to Hand / Auto
Linked to Hand / Auto
Local
Remote
determines what kind of application control principle (i.e. Speed, Torque or Process Control) is used when the Remote
determines the kind of application control principle that is used when the Local reference is made active.
MG.33.BC.02 - VLT
Active Reference
Local
Local
Remote
Remote
Local
Remote
