Danfoss FC 300 Design Manual page 100

5 How to Order
Ordering type codemodel number frame size F
Description Pos
Product group 1-3
Drive series 4-6
Power rating 8-10
Phases 11
Mains voltage 11-
12
Enclosure 13-
15
5
RFI filter 16-
17
Brake 18
Display 19
Coating PCB 20
Mains option 21
100
Possible choice
AutomationDrive FC 302
AutomationDrive FC 302
450 - 1200 kW
Three phases (T)
T 5: 380-500 V AC
T 7: 525-690 V AC
E21: IP 21/ NEMA Type 1
E54: IP 54/ NEMA Type 12
L2X: IP21/NEMA 1 with cabinet light &
IEC 230V power outlet
L5X: IP54/NEMA 12 with cabinet light &
IEC 230V power outlet
L2A: IP21/NEMA 1 with cabinet light &
NAM 115V power outlet
L5A: IP54/NEMA 12 with cabinet light &
NAM 115V power outlet
H21: IP21 with space heater and ther-
mostat
H54: IP54 with space heater and ther-
mostat
R2X: IP21/NEMA1 with space heater,
thermostat, light & IEC 230V outlet
R5X: IP54/NEMA12 with space heater,
thermostat, light & IEC 230V outlet
R2A: IP21/NEMA1 with space heater,
thermostat, light, & NAM 115V outlet
R5A: IP54/NEMA12 with space heater,
thermostat, light, & NAM 115V outlet
H2: RFI filter, class A2 (standard)
H4: RFI filter, class A1 2, 3)
2)
HE: RCD with Class A2 RFI filter
2, 3)
HF: RCD with class A1 RFI filter
2)
HG: IRM with Class A2 RFI filter
2, 3)
HH: IRM with class A1 RFI filter
HJ: NAMUR terminals and class A2 RFI
filter 1)
HK: NAMUR terminals with class A1 RFI
filter 1, 2, 3)
HL: RCD with NAMUR terminals and
1, 2)
class A2 RFI filter
HM: RCD with NAMUR terminals and
class A1 RFI filter 1, 2, 3)
HN: IRM with NAMUR terminals and
1, 2)
class A2 RFI filter
HP: IRM with NAMUR terminals and
class A1 RFI filter 1, 2, 3)
B: Brake IGBT mounted
X: No brake IGBT
R: Regeneration terminals
M: IEC Emergency stop pushbutton
(with Pilz safety relay) 4)
N: IEC Emergency stop pushbutton
with brake IGBT and brake terminals
P: IEC Emergency stop pushbutton with
regeneration terminals 4)
G: Graphical Local Control Panel LCP
C: Coated PCB
X: No mains option
3 2) : Mains disconnect and Fuse
5 2) : Mains disconnect, Fuse and Load
sharing
7: Fuse
A: Fuse and Load sharing
D: Load sharing
E: Mains disconnect, contactor &
fuses 2)
F: Mains circuit breaker, contactor &
fuses 2)
G: Mains disconnect, contactor, load-
sharing terminals & fuses 2)
H: Mains circuit breaker, contactor,
loadsharing terminals & fuses 2)
J: Mains circuit breaker & fuses 2)
K: Mains circuit breaker, loadsharing
2)
terminals & fuses
MG.33.BC.02 - VLT
Description Pos
Power Terminals 22
& Motor Starters
Auxiliary 24V 23
Supply & Exter-
nal Temperature
Monitoring
Software release 24-
27
Software lan- 28
guage
1) MCB 113 Extended Relay Card and MCB 112 PTC Thermistor Card
required for NAMUR terminals
2) F3 and F4 frames only
3) 380-480/500 V only
4) Requires contactor
Ordering type codemodel number, options (all frame sizes)
Description Pos
A options 29-
30
B options 31-
32
4)
C0/ E0 options 33-
34
C1 options/ A/B 35
in C Option
Adaptor
C option soft- 36-
ware/ E1 options 37
D options 38-
39
® is a registered Danfoss trademark
FC 300 Design Guide
Possible choice
X: No option
E 30 A, fuse-protected power terminals
F: 30A, fuse-protected power terminals
& 2.5-4 A manual motor starter
G: 30A, fuse-protected power terminals
& 4-6.3 A manual motor starter
H: 30A, fuse-protected power terminals
& 6.3-10 A manual motor starter
J: 30A, fuse-protected power terminals
& 10-16 A manual motor starter
K: Two 2.5-4 A manual motor starters
L: Two 4-6.3 A manual motor starters
M: Two 6.3-10 A manual motor starters
N: Two 10-16 A manual motor starters
X: No option
H: 5A, 24V power supply (customer
use)
J: External temperature monitoring
G: 5A, 24V power supply (customer
use) & external temperature monitoring
Actual software
Possible choice
AX: No A option
A0: MCA 101 Profibus DP V1 (standard)
A1: MCA 101 Profibus DP V1 (with top-
entry)
A4: MCA 104 DeviceNet (standard)
A4: MCA 104 DeviceNet (with top-en-
try)
A6: MCA 105 CANOpen (standard)
A6: MCA 105 CANOpen (with top-entry)
AN: MCA 121 Ethernet IP
AT: MCA 113 Profibus converter
VLT3000
AY: MCA 123 Ethernet PowerLink
BX: No option
BK: MCB 101 General purpose I/O op-
tion
BR: MCB 102 Encoder option
BU: MCB 103 Resolver option
BP: MCB 105 Relay option
BZ: MCB 108 Safety PLC Interface
B2: MCB 112 PTC Thermistor Card
CX: No option
C4: MCO 305, Programmable Motion
Controller
BK: MCB-101 General purpose I/O in E0
BZ: MCB-108 Safety PLC Interface in E0
X: No option
R: MCB 113 Ext. Relay Card
Z: MCA-140 Modbus RTU OEM option
E: MCF 106 A/B in C Option Adaptor
XX: Standard controller
10: MCO 350 Synchronizing control
11: MCO 351 Positioning control
12: MCO 352 Center winder
AN: MCA-121 Ethernet IP in E1
BK:MCB-101 General purpose I/O in E1
BZ: MCB-108 Safety PLC Interface in E1
DX: No option
D0: DC back-up
D0: MCB 107 Ext. 24 V back-up
