11 RS-485 Installation and Set-up
Bit Bit = 0
00 OFF 1
01 OFF 2
02 OFF 3
03 Coasting
04 Quick stop
05 Hold frequency output
06 Ramp stop
07 No function
08 Jog 1 OFF
09 Jog 2 OFF
10 Data invalid
11 No function
12 No function
13 Parameter set-up
14 Parameter set-up
15 No function
Explanation of the Control Bits
Bit 00, OFF 1/ON 1
Normal ramp stop using the ramp times of the actual selected ramp.
Bit 00 = "0" leads to the stop and activation of the output relay 1 or 2 if the output frequency is 0 Hz and if [Relay 123] has been selected in
par. 5-40 Function Relay
When bit 00 = "1", the frequency converter is in State 1: "Switching on inhibited".
Please refer to the PROFIdrive State Transition Diagram, at the end of this section.
Bit 01, OFF 2/ON 2
Coasting stop
When bit 01 = "0", a coasting stop and activation of the output relay 1 or 2 occurs if the output frequency is 0 Hz and if [Relay 123] has been selected
Function Relay
in par. 5-40
11
When bit 01 = "1", the frequency converter is in State 1: "Switching on inhibited". Please refer to the PROFIdrive State Transition Diagram, at the end
of this section.
Bit 02, OFF 3/ON 3
Quick stop using the ramp time of par. 3-81
the output frequency is 0 Hz and if [Relay 123] has been selected in par. 5-40
When bit 02 = "1", the frequency converter is in State 1: "Switching on inhibited".
Please refer to the PROFIdrive State Transition Diagram, at the end of this section.
Bit 03, Coasting/No coasting
Coasting stop Bit 03 = "0" leads to a stop. When bit 03 = "1", the frequency converter can start if the other start conditions are satisfied.
NB!
The selection in par. 8-50
inputs.
Bit 04, Quick stop/Ramp
Quick stop using the ramp time of par. 3-81
When bit 04 = "0", a quick stop occurs.
When bit 04 = "1", the frequency converter can start if the other start conditions are satisfied.
250
Bit = 1
ON 1
ON 2
ON 3
No coasting
Ramp
Use ramp
Start
Reset
Jog 1 ON
Jog 2 ON
Data valid
Slow down
Catch up
Selection lsb
Selection msb
Reverse
.
.
Quick Stop Ramp Time
Coasting Select
Coasting select determines how bit 03 is linked with the corresponding function of the digital
Quick Stop Ramp Time
MG.33.BC.02 - VLT
. When bit 02 = "0", a quick stop and activation of the output relay 1 or 2 occurs if
Function Relay .
.
