FC 300 Design Guide
Mains Supply 3 x 525- 690 VAC
AutomationDrive FC 302
High/ Normal Load*
Typical Shaft output at 550
V [kW]
Typical Shaft output at 575
V [HP]
Typical Shaft output at 690
V [kW]
Enclosure IP21
Enclosure IP54
Enclosure IP00
Output current
Continuous
(at 550 V) [A]
Intermittent (60 sec over-
load)
(at 550 V) [A]
Continuous
(at 575/ 690 V) [A]
Intermittent (60 sec over-
load)
(at 575/ 690 V) [A]
Continuous KVA
(at 550 V) [KVA]
Continuous KVA
(at 575 V) [KVA]
Continuous KVA
(at 690 V) [KVA]
Max. input current
Continuous
(at 550 V ) [A]
Continuous
(at 575 V) [A]
Continuous
(at 690 V) [A]
Max. cable size, mains mo-
tor, load share and brake
2
[mm
Max. external mains fuses
[A] 1
Estimated power loss
at 600 V [W]
Estimated power loss
at 690 V [W]
Weight,
Enclosure IP21, IP 54 [kg]
Weight,
Enclosure IP00 [kg]
Efficiency
Output frequency
Heatsink overtemp. trip
Power card ambient trip
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s
P110
HO
90
125
110
D1
D1
D3
137
206
131
197
131
130
157
130
124
128
2 x 70 (2 x 2/0)
(AWG)]
315
2536
4)
2664
4)
96
82
4)
85 °C
MG.33.BC.02 - VLT ® is a registered Danfoss trademark
4 AutomationDrive FC 300 Selection
P132
NO HO NO
110 110 132 132
150 150 200 200
132 132 160 160
D1
D1
D3
162 162 201 201
178 243 221 302
155 155 192 192
171 233 211 288
154 154 191 191
154 154 191 191
185 185 229 229
158 158 198 198
151 151 189 189
155 155 197 197
2 x 150 (2 x 300
2 x 70 (2 x 2/0)
350
2963 2806 3430 3261
3114 2953 3612 3451
104
91
0.98
0 - 600 Hz
90 °C
60 °C
P160 P200
HO NO HO NO
160 160 200
250 250 300
200 200 250
D2 D2
D2 D2
D4 D4
253 253 303
278 380 333
242 242 290
266 363 319
241 241 289
241 241 289
289 289 347
245 245 299
234 234 286
240 240 296
2 x 150 (2 x 300
mcm) mcm)
350 400
4051 4037 4867
4292 4275 5156
125 136
112 123
110 °C 110 °C
