Danfoss FC 300 Design Manual page 106

5 How to Order
AutomationDrive FC 302 - Mains: 525-600V (T6) - 10% Duty Cycle
Automation P
m (HO)
Drive FC 302
T6 [kW]
PK75 0.75
P1K1 1.1
P1K5 1.5
P2K2 2.2
P3K0 3
P4K0 4
P5K5 5.5
P7K5 7.5
P11K 11
5
P15K 15
P18K 18.5
P22K 22
P30K 30
P37K 37
P45K 45
P55K 55
P75K 75
P90K 90
P110 110
P132 132
P160 160
P200 200
P250 250
P315 315
P355 355
P400 400
P450 450
P500 500
P560 560
P670 670
P750 750
P850 850
P1M0 1000
P1M1 1100
AutomationDrive FC 302 - Mains: 525-690V (T7) - 10% Duty Cycle
AutomationDriv P
m (HO)
e FC 302
T7 [kW]
P400 400
P500 500
P560 560
P630 630
P710 710
P800 800
P900 900
P1M1 1000
P1M2 1200
106
R R R
min br, nom rec
[Ω] [Ω] [Ω]
620 904 620
550 613 620
380 447 425
270 301 310
189 218 210
135 162 150
99 116 110
72 84.5 80
40 57 40
36 41.3 40
27 33.2 30
22.5 27.6 25
18 21.6 20
13.5 17.3 15
10.8 14.2 12
8.8 11.6 9.8
6.6 8.4 7.3
4.7 7 4.7
4.7 5.8 4.7
4.2 4.8 4.7
3.4 4 3.8
2.7 3.2 5.2 / 2 = 2.6 36 x 2 = 72
2.2 2.5 5.2 / 2 = 2.6 36 x 2 = 72
1.7 2
1.6 1.8
1.4 1.6
1.2 1.3
1.2 1.3
1.2 1.3
1.2 1.3
1.2 1.3
1.2 1.3
1.2 1.3
1.2 1.3
R R R
min br, nom rec
[Ω] [Ω] [Ω]
1.9 2.2 4.2 / 2 = 2.1
1.5 1.7 4.2 / 2 = 2.1
1.4 1.5 4.2 / 2 = 2.1
1.2 1.4 4.2 / 2 = 2.1
1.2 1.3 4.2 / 2 = 2.1
1.2 1.3 4.2 / 2 = 2.1
1.2 1.3 4.2 / 2 = 2.1
1.2 1.3 4.2 / 2 = 2.1
1.2 1.3 4.2 / 2 = 2.1
MG.33.BC.02 - VLT
P Order no. Period
br avg
[kW] 175Uxxxx [s]
0.1 1840 120
0.1 1840 120
0.1 1841 120
0.3 1842 120
0.3 1843 120
0.4 1844 120
0.6 1845 120
0.9 1846 120
2 1848 120
2 1848 120
2.8 1849 120
3.5 1850 120
4 1851 120
4.8 1852 120
5.5 1853 120
15 2008 120
13 0069 120
18 1959 300
18 1959 300
18 1959 300
22 1960 300
2 x 1062 300
2 x 1062 300
P Order no. Period
br avg
[kW] 175Uxxxx
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
50 x 2 = 100 2 x 1064
® is a registered Danfoss trademark
FC 300 Design Guide
Cable cross Therm. Max. brake torque
relay with R
section 2 *
rec
[mm2] [A] [%]
1.5 0.3 160 (160)
1.5 0.3 160 (160)
1.5 0.5 160 (160)
1.5 0.9 160 (160)
1.5 1.2 160 (160)
1.5 1.7 160 (160)
1.5 2.3 160 (160)
1.5 3.3 160 (160)
1.5 3.9 160 (160)
1.5 7.1 160 (160)
1.5 9.7 160 (160)
1.5 12 150 (150)
1.5 14 150 (150)
2.5 18 150 (150)
2.5 21 150 (150)
10 39 150 (150)
10 42 150 (150)
16 62 150 (150)
16 62 150 (150)
16 62 150 (150)
25 76 150 (150)
5 166 150 (150)
2 x 70 *
5 166 146 (150)
2 x 70 *
(150)
(150)
(150)
(150)
(150)
(130)
(116)
(103)
(91)
(73)
Cable cross Max. brake torque
section with R *
rec
[s] [mm2] [%]
300 2 x 120 150 (150)
300 2 x 120 123 (150)
300 2 x 120 118 (150)
300 2 x 120 98 (150)
300 2 x 120 87 (140)
300 2 x 120 77 (124)
300 2 x 120 68 (110)
300 2 x 120 61 (99)
300 2 x 120 51 (83)
*
