4 AutomationDrive FC 300 Selection

4.5 General Specifications

Mains supply (L1, L2, L3):
Supply voltage
Supply voltage
Supply voltage
Mains voltage low / mains drop-out:
During low mains voltage or a mains drop-out, the FC continues until the intermediate circuit voltage drops below the minimum stop level, which
corresponds typically to 15% below the FC's lowest rated supply voltage. Power-up and full torque cannot be expected at mains voltage lower than
4
10% below the FC's lowest rated supply voltage.
Supply frequency
Max. imbalance temporary between mains phases
True Power Factor (λ)
Displacement Power Factor (cos ϕ)
Switching on input supply L1, L2, L3 (power-ups) ≤ 7.5 kW
Switching on input supply L1, L2, L3 (power-ups) 11-75 kW
Switching on input supply L1, L2, L3 (power-ups) ≥ 90 kW
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/500/600/ 690 V maximum.
Motor output (U, V, W):
Output voltage
Output frequency (0.25-75 kW)
Output frequency (90-1000 kW)
Output frequency in Flux Mode (AutomationDrive FC 302 only)
Switching on output
Ramp times
* Voltage and power dependent
Torque characteristics:
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
Starting torque (Variable torque)
Overload torque (Variable torque)
*Percentage relates to the nominal torque.
Cable lengths and cross sections for control cables*:
Max. motor cable length, screened
Max. motor cable length, unscreened
Maximum cross section to control terminals, flexible/ rigid wire without cable end sleeves
Maximum cross section to control terminals, flexible wire with cable end sleeves
Maximum cross section to control terminals, flexible wire with cable end sleeves with collar
Minimum cross section to control terminals
* Power cables, see tables in section "Electrical Data" of the Design Guide
78
AutomationDrive FC 301: 380-480 V / AutomationDrive FC 302: 380-500 V ±10%
AutomationDrive FC 301: 0.2 - 1000 Hz / AutomationDrive FC 302: 0 - 1000 Hz
AutomationDrive FC 301: 50 m / AutomationDrive FC 301 (A1): 25 m/ AutomationDrive FC 302: 150 m
AutomationDrive FC 301: 75 m / AutomationDrive FC 301 (A1): 50 m/ AutomationDrive FC 302: 300 m
MG.33.BC.02 - VLT
®
is a registered Danfoss trademark
FC 300 Design Guide
200-240 V ±10%
AutomationDrive FC 302: 525-690 V ±10%
50/60 Hz ±5%
3.0 % of rated supply voltage
≥ 0.9 nominal at rated load
near unity (> 0.98)
maximum 2 times/min.
maximum 1 time/min.
maximum 1 time/2 min.
overvoltage category III/pollution degree 2
0 - 100% of supply voltage
0 - 800* Hz
0 - 300 Hz
Unlimited
0.01 - 3600 sec.
maximum 160% for 60 sec.
maximum 180% up to 0.5 sec.
maximum 160% for 60 sec.
maximum 110% for 60 sec.
maximum 110% for 60 sec.
2
1.5 mm
/16 AWG
1 mm
2
/18 AWG
0.5 mm
2
/20 AWG
0.25 mm
2
/ 24 AWG
*
*
*
*
