FC 300 Design Guide
UL Compliance - max. fuse size
The fuses below are suitable for use on a circuit capable of delivering 100,000 Arms (symmetrical), 240V, or 480V, or 500V, or 600V depending on the
drive voltage rating. With the proper fusing the drive Short Circuit Current Rating (SCCR) is 100,000 Arms.
200-240 V
Bussmann
kW Type RK1
K25-K37 KTN-R05
K55-1K1 KTN-R10
1K5 KTN-R15
2K2 KTN-R20
3K0 KTN-R25
3K7 KTN-R30
5K5 KTN-R50
7K5 KTN-R60
11K KTN-R80
15K-18K5 KTN-R125
kW
K25-K37 5017906-005
K55-1K1 5017906-010
1K5 5017906-016
2K2 5017906-020
3K0 5017906-025
3K7 5012406-032
5K5 5014006-050
7K5 5014006-063
11K 5014006-080
15K-18K5 2028220-125
Bussmann
kW Type JFHR2
22K FWX-150
30K FWX-200
37K FWX-250
KTS-fuses from Bussmann may substitute KTN for 240 V frequency converters.
FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
KLSR fuses from LITTEL FUSE may substitute KLNR fuses for 240 V frequency converters.
L50S fuses from LITTEL FUSE may substitute L50S fuses for 240 V frequency converters.
A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V frequency converters.
A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V frequency converters.
380-500 V, frame sizes A, B and C
Bussmann
kW Type RK1
K37-1K1 KTS-R6
1K5-2K2 KTS-R10
3K0 KTS-R15
4K0 KTS-R20
5K5 KTS-R25
7K5 KTS-R30
11K KTS-R40
15K KTS-R50
18K KTS-R60
22K KTS-R80
30K KTS-R100
37K KTS-R125
45K KTS-R150
Bussmann Bussmann
Type J Type T
JKS-05 JJN-06
JKS-10 JJN-10
JKS-15 JJN-15
JKS-20 JJN-20
JKS-25 JJN-25
JKS-30 JJN-30
KS-50 JJN-50
JKS-60 JJN-60
JKS-80 JJN-80
JKS-150 JJN-125
SIBA Littel fuse
Type RK1 Type RK1
KLN-R05
KLN-R10
KLN-R15
KLN-R20
KLN-R25
KLN-R30
KLN-R50
KLN-R60
KLN-R80
KLN-R125
SIBA
Type RK1
2028220-150
2028220-200
2028220-250
Bussmann Bussmann
Type J Type T
JKS-6 JJS-6
JKS-10 JJS-10
JKS-15 JJS-15
JKS-20 JJS-20
JKS-25 JJS-25
JKS-30 JJS-30
JKS-40 JJS-40
JKS-50 JJS-50
JKS-60 JJS-60
JKS-80 JJS-80
JKS-100 JJS-100
JKS-150 JJS-150
JKS-150 JJS-150
MG.33.BC.02 - VLT ® is a registered Danfoss trademark
Bussmann Bussmann
Type CC Type CC
FNQ-R-5 KTK-R-5
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
- -
- -
- -
- -
Ferraz-
Shawmut
Type CC
ATM-R05
ATM-R10
ATM-R15
ATM-R20
ATM-R25
ATM-R30
-
-
-
-
Littel fuse
JFHR2
L25S-150
L25S-200
L25S-250
Bussmann Bussmann
Type CC Type CC
FNQ-R-6 KTK-R-6
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
- -
- -
- -
- -
- -
- -
- -
8 Electrical Installation
Bussmann
Type CC
LP-CC-5
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
-
-
-
-
Ferraz-
Shawmut
Type RK1
A2K-05R
A2K-10R
A2K-15R
A2K-20R
A2K-25R
A2K-30R
A2K-50R
A2K-60R
A2K-80R
8
A2K-125R
Ferraz-
Shawmut
JFHR2
A25X-150
A25X-200
A25X-250
Bussmann
Type CC
LP-CC-6
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
-
-
-
-
-
-
-
