9 Application Examples
Parameter set-up Torque open loop in VVC+ mode
Function
Basic Settings
Configuration Mode
Motor Control Principle
Torque PI control settings
Torque PI Proportional Gain
Torque PI Integration Time
Reference Handling (Nm) Reference 53; Limit 54
Reference range
Terminal 53 Low Voltage
Terminal 53 High Voltage
Terminal 53 Low Ref.
Terminal 53 High Ref
Speed Limit Factor Adjustable on input 54
Speed Limit Factor Source Operation
Terminal 54 Low Voltage
Terminal 54 High Voltage
Terminal 54 Low Ref
Terminal 54 High Ref
9
206
Parameter Setting
1-00 Torque Open Loop
1-01 VVC+
7-12 Default 100 %
7-13 Default 0.02 sec
3-00 Min - max
6-10 0V (Default 0.07V)
6-11 10V
6-14 0 Nm
6-15 Max torque on motor shaft
4-21 Analog Input 54
6-20 0V (default 0.07V)
6-21 10 V
6-24 0V
6-25 1500 rpm (adjustable set-
ting)
MG.33.BC.02 - VLT ® is a registered Danfoss trademark
FC 300 Design Guide
Data Value
[4]
[1]
[0]
[6]
