5 How to Order
5.2.10 Ordering Numbers: du/dt Filters, 380-480/500 VAC
Mains supply 3x380-500 V
3 x 380-500 V
Minimum switch-
Rated filter cur- ing frequency
rent at 50 Hz
24
45
75
110
182
280
400
500
750
910
1500
5
5.2.11 Ordering Numbers: du/dt Filters, 525-690 VAC
Mains supply 3x525-690 V
3 x 525-690 V
Rated filter cur-
rent at 50 Hz
28
45
75
115
165
260
310
430
530
630
765
1350
116
Maximum output
frequency [Hz]
[kHz] with Derating
4 100
4 100
3 100
3 100
3 100
3 100
3 100
3 100
2 100
2 100
2 100
Minimum Maximum output
switching fre- frequency [Hz]
quency [kHz] with Derating
3 100
2 100
2 100
2 100
2 100
2 100
2 100
1,5 100
1,5 100
1,5 100
1,5 100
1,5 100
MG.33.BC.02 - VLT
Danfoss IP20 Danfoss IP00
130B2396 130B2385
130B2397 130B2386
130B2398 130B2387
130B2399 130B2388
130B2400 130B2389
130B2401 130B2390
130B2402 130B2391
130B2277 130B2275
130B2278 130B2276
130B2405 130B2393
130B2407 130B2394
Danfoss IP20 Danfoss IP00
130B2423 130B2414
130B2424 130B2415
130B2425 130B2416
130B2426 130B2417
130B2427 130B2418
130B2428 130B2419
130B2429 130B2420
130B2238 130B2235
130B2239 130B2236
130B2274 130B2280
130B2430 130B2421
130B2431 130B2422
