8 Electrical Installation
Frame size:
A5
B1
B2
C1 37 kW
C1 45-55 kW
C2 75 kW
C2 90 kW
8.4.2 Mains Disconnectors - Frame Size D, E and F
Frame size
D1/D3
D2/D4
E1/E2
E1/E2
F3
F3
F4
8
8.4.3 F-Frame Circuit Breakers
Frame size
F3
F3
F4
F4
8.4.4 F-Frame Mains Contactors
Frame size
F3
F3
F3
F4
F4
8.5 Additional Motor Information
8.5.1 Motor Cable
The motor must be connected to terminals U/T1/96, V/T2/97, W/T3/98. Earth to terminal 99. All types of three-phase asynchronous standard motors
can be used with a frequency converter unit. The factory setting is for clockwise rotation with the frequency converter output connected as follows:
Terminal No.
96, 97, 98, 99
174
Type:
Kraus&Naimer KG20A T303
Kraus&Naimer KG64 T303
Kraus&Naimer KG64 T303
Kraus&Naimer KG100 T303
Kraus&Naimer KG105 T303
Kraus&Naimer KG160 T303
Kraus&Naimer KG250 T303
Power & Voltage
P90K-P110 380-500V & P90K-P132 525-690V
P132-P200 380-500V & P160-P315 525-690V
P250 380-500V & P355-P560 525-690V
P315-P400 380-500V
P450 380-500V & P630-P710 525-690V
P500-P630 380-500V & P800 525-690V
P710-P800 380-500V & P900-P1M0 525-690V
Power & Voltage
P450 380-500V & P630-P710 525-690V
P500-P630 380-500V & P800 525-690V
P710 380-500V & P900-P1M0 525-690V
P800 380-500V
Power & Voltage
P450-P500 380-500V & P630-P800 525-690V
P560 380-500V
P630380-500V
P900 525-690V
P710-P800 380-500V & P1M0 525-690V
Function
Mains U/T1, V/T2, W/T3
Earth
MG.33.BC.02 - VLT
Terminal connections:
Type
ABB OETL-NF200A or OT200U12-91
ABB OETL-NF400A or OT400U12-91
ABB OETL-NF600A
ABB OETL-NF800A
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NRK36000S20AAYP
Merlin Gerin NRK36000S20AAYP
Type
Merlin Gerin NPJF36120U31AABSCYP
Merlin Gerin NRJF36200U31AABSCYP
Merlin Gerin NRJF36200U31AABSCYP
Merlin Gerin NRJF36250U31AABSCYP
Type
Eaton XTCE650N22A
Eaton XTCE820N22A
Eaton XTCEC14P22B
Eaton XTCE820N22A
Eaton XTCEC14P22B
