FC 300 Design Guide
Ordering type codemodel number frame sizes A, B and C
Description
Pos
Possible choice
Product group
1-3
FC 30x
Drive series
4-6
AutomationDrive FC 301
AutomationDrive FC 302
Power rating
8-10
0.25-75 kW
Phases
11
Three phases (T)
Mains voltage
11-
T 2: 200-240 V AC
12
T 4: 380-480 V AC
T 5: 380-500 V AC
T 6: 525-600 V AC
T 7: 525-690 V AC
Enclosure
13-
E20: IP20
15
E55: IP 55/NEMA Type 12
P20: IP20 (with back plate)
P21: IP21/ NEMA Type 1 (with back
plate)
P55: IP55/ NEMA Type 12 (with back
plate)
Z20: IP 20
E66: IP 66
RFI filter
16-
H1: RFI filter class A1/B1
17
H2: No RFI filter, observes class A2
H3: RFI filter class A1/B1
H6: RFI filter Maritime use
HX: No filter (600 V only)
Brake
18
B: Brake chopper included
X: No brake chopper included
T: Safe Stop No brake
U: Safe stop brake chopper
Display
19
G: Graphical Local Control Panel (LCP)
N: Numerical Local Control Panel (LCP)
X: No Local Control Panel
Coating PCB
20
C: Coated PCB
X. No coated PCB
Mains option
21
X: No mains option
1: Mains disconnect
3: Mains disconnect and Fuse
5: Mains disconnect, Fuse and Load
sharing
7: Fuse
8: Mains disconnect and Load sharing
A: Fuse and Load sharing
D: Load sharing
Adaptation
22
Reserved
Adaptation
23
Reserved
Software release 24-
Actual software
27
Software lan-
28
guage
1): AutomationDrive FC 301/ frame sizeA1 only
2) US Market only
3): Power sizes ≥ 11 kW only
1)
1)
1)
1)
1)
2)
2, 3)
2)
3)
2, 3)
3)
MG.33.BC.02 - VLT
®
is a registered Danfoss trademark
Ordering type codemodel number frame sizes D and E
Description
Pos
Possible choice
Product group 1-3
AutomationDrive FC 302
Drive series
4-6
AutomationDrive FC 302
Power rating
8-10
37-560 kW
Phases
11
Three phases (T)
Mains voltage
11-
T 5: 380-500 V AC
12
T 7: 525-690 V AC
Enclosure
13-
E00: IP00/Chassis
15
C00: IP00/Chassis w/ stainless steel
back channel
E0D: IP00/Chassis, D3 P37K-P75K, T7
C0D: IP00/Chassis w/ stainless steel
back channel, D3 P37K-P75K, T7
E21: IP 21/ NEMA Type 1
E54: IP 54/ NEMA Type 12
E2D: IP 21/ NEMA Type 1, D1 P37K-
P75K, T7
E5D: IP 54/ NEMA Type 12, D1 P37K-
P75K, T7
E2M: IP 21/ NEMA Type 1 with mains
shield
E5M: IP 54/ NEMA Type 12 with mains
shield
RFI filter
16-
H2: RFI filter, class A2 (standard)
17
H4: RFI filter class A1
H6: RFI filter Maritime use
Brake
18
B: Brake IGBT mounted
X: No brake IGBT
R: Regeneration terminals (E frames
only)
Display
19
G: Graphical Local Control Panel LCP
N: Numerical Local Control Panel (LCP)
X: No Local Control Panel (D frames
IP00 and IP 21 only)
Coating PCB
20
C: Coated PCB
X. No coated PCB (D frames
380-480/500 V only)
Mains option
21
X: No mains option
3: Mains disconnect and Fuse
5: Mains disconnect, Fuse and Load
sharing
7: Fuse
A: Fuse and Load sharing
D: Load sharing
Adaptation
22
Reserved
Adaptation
23
Reserved
Software re-
24-
Actual software
lease
27
Software lan-
28
guage
1): Available for all D frames. E frames 380-480/500 V only
2) Consult factory for applications requiring maritime certification
5 How to Order
5
1)
2)
99
