(2) Machine (rear side)
34
34. DP interface connector cover
35. DP interface connector
36. Cassette heater switch
37. Inlet connector
38. Coin vender connector
39. Network interface connector
40. USB port
35
36
44
37
38
Figure 1-1-3
1-1-7
39 41
41. USB interface connector
42. Option interface slot 2
43. Option interface slot 1
44. FAX memory cover
45. Scanner lock cover
2NP
45
42
43
40
