Item No.
U240

Checking the operation of the finisher

Description
Turns each motor and solenoid of 1000-sheet finisher ON.
Purpose
To check the operation of each motor and solenoid of the 1000-sheet finisher.
Method
1. Press the start key.
2. Select the item to be checked.
Motor
Solenoid
Mail Box
Booklet
Method: [Motor]
1. Select the item to be operated.
2. Press the start key. The operation starts.
Feed In(H)
Feed In(L)
Middle(H)
Middle(L)
Eject(H)
Eject(L)
Save(H)
Save(L)
Tray
Staple Move
Staple
Width Test(A3)
Width Test(LD)
Beat
Eject Unlock(HP)
Sort Test
Eject Unlock(30)
Eject Unlock(50)
Eject Unlock(Fix)
Display
Checking the motor of the document finisher
Checking the solenoid of the document finisher
Checking the motor of the mailbox
Checking the motor of the center-folding unit
Display
DF paper entry motor (DFPEM) is turned on at high speed
DF paper entry motor (DFPEM) is turned on at low speed
DF middle motor (DFMM) is turned on at high speed
DF middle motor (DFMM) is turned on at low speed
DF eject motor (DFEM) is turned on at high speed
DF eject motor (DFEM) is turned on at low speed
DF drum motor (DFDRM) is turned on at high speed
DF drum motor (DFDRM) is turned on at low speed
DF tray motor (DFTM) is turned on
DF slide motor (DFSLM) is turned on
DF staple motor (DFSTM) is turned on
DF side registration motor 1, 2 (DFSRM1, 2) is turned on
DF side registration motor 1, 2 (DFSRM1, 2) is turned on
DF paddle motor (DFPDM) is turned on
DF eject release motor (DFERM) is turned on to home position
DF shift motor 1, 2 (DFSFM1, 2) is turned on
DF eject release motor (DFERM) drive position 30-sheet stack
DF eject release motor (DFERM) drive position 50-sheet stack
DF eject release motor (DFERM) fixed drive position
Description
Description
Description
1-3-103
2NP
