Item No.
U150

Checking sensors for toner

Description
Displays the on-off status of each sensor or switch related to toner.
Purpose
To check if the sensors and switches operate correctly.
Method
1. Press the start key.
2. Select the item. The screen for executing each item is displayed.
T/C
Waste Box
Method: [T/C]
1. Turn each switch or sensor on and off manually to check the status.
When a switch or sensor is detected to be in the ON position, the display for that switch or
sensor will be "1"
T/C Sensor (C)
T/C Sensor (M)
T/C Sensor (Y)
T/C Sensor (K)
Motor
Last print (C)
Last print (M)
Last print (Y)
Last print (K)
2. To stop motor driving, press the stop key.
Display
Displays the state of the toner sensor.
Displays the state of the waste toner box.
Display
Displays the state of the toner sensor (Cyan).
Displays the state of the toner sensor (Magenta).
Displays the state of the toner sensor (Yellow).
Displays the state of the toner sensor (Black).
Drives developer motor, developer clutch.
Displays the state of the toner sensor at the time of the last
printing (Cyan).
Displays the state of the toner sensor at the time of the last
printing (Magenta).
Displays the state of the toner sensor at the time of the last
printing (Yellow).
Displays the state of the toner sensor at the time of the last
printing (Black).
Description
Description
Switches and sensors
