Item No.
U632

Setting communication control 3

Description
Makes settings for fax transmission regarding the communication.
Method
1. Press the start key.
2. Select the item to be set.
DIS 4Byte
Num OF CNG(F/T)
Setting:[DIS 4Byte]
Sets if bit 33 and later bits of the DIS/DTC signal are sent.
1. Select the setting.
On
Off
* : Initial setting: Off
2. Press the start key. The setting is set.
Setting:[Num OF CNG(F/T)]
Sets the CNG detection times in the fax/telephone auto select mode.
1. Select the setting.
1Time
2Time
* : Initial setting: 2Time
2. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Display
Sets the DIS signal to 4 bytes.
Sets the CNG detection times in the fax/telephone auto select
mode.
Display
Bit 33 and later bits of the DIS/DTC signal are not sent.
Bit 33 and later bits of the DIS/DTC signal are sent.
Display
Detects CNG once.
Detects CNG twice.
Description
Description
Description
Description
1-3-175
